TC input:
Min.
Type
value
B
+400°C
+1820°C
E
-100°C
+1000°C
J
-100°C
+1200°C
K
-180°C
+1372°C
L
-200°C
+900°C
N
-180°C
+1300°C
R
-50°C
+1760°C
S
-50°C
+1760°C
T
-200°C
+400°C
U
-200°C
+600°C
W3
0°C
+2300°C
W5
0°C
+2300°C
Ext. CJC
-40°C
+135°C
Cold junction compensation (CJC) ............. < ±0.5 °C
Sensor error detection ................................ Yes
Sensor error current:
when detecting ....................................... Nom. 4 µA
else .......................................................... 0 µA
Short circuit detection ................................. < 3 mV
Voltage input:
Measurement range .................................... -800...+800 mV
Input resistance ........................................... 10 MΩ
Output:
®
connection:
PROFIBUS
PA
®
protocol .............................. Profile A&B, ver. 3.0
PROFIBUS
PA
®
PROFIBUS
PA
protocol standard ............... EN 50170 vol. 2
®
address (at delivery) ........... 126
PROFIBUS
PA
®
PROFIBUS
PA
function blocks ................... 2 analogue
TM
F
Fieldbus connection:
OUNDATION
TM
F
Fieldbus protocol ................. FF protocol
OUNDATION
F
TM
Fieldbus protocol standard .. FF design specifications
OUNDATION
TM
F
Fieldbus capability ............... Basic or LAS
OUNDATION
F
TM
Fieldbus version ................... ITK 4.6
OUNDATION
TM
F
Fieldbus function blocks ...... 2 analogue and 1 PID
OUNDATION
24
24
All manuals and user guides at all-guides.com
Max.
value
Standard
IEC584
IEC584
IEC584
IEC584
DIN 43710
IEC584
IEC584
IEC584
IEC584
DIN 43710
ASTM E988-90
ASTM E988-90
IEC6075
Ex approval - 5350A:
KEMA 03ATEX1011 X
Ex data:
Terminal 1, 2 (Fieldbus circuit):
II 3 G EEx nA [nL] II C T4...T6
U
................................................................. : 32 VDC
i
or
II 3 G EEx nL II C T4...T6
U
................................................................. : 32 VDC
i
................................................................. : 1 µH
L
i
C
................................................................. : 2 nF
i
or
FNICO field device
U
................................................................. : 17.5 VDC
i
with cable parameters:
................................................................ : 15...150 Ω/km
R
c
L
................................................................ : 0.4...1 mH/km
c
C
................................................................ : 45...200 nF/km
c
Spur cable length max. 60 m in IIC and IIB.
Trunk cable length inclusive length of all spurs max. 1 km in IIC and 5 km in IIB.
Terminal 3, 4, 5 and 6 (sensor circuit):
U
................................................................ : 5.7 VDC
o
I
................................................................. : 8.4 mA
o
P
................................................................ : 12 mW
o
L
................................................................ : 200 mH
o
C
................................................................ : 40 µF
o
FM, UL and CSA ......................................... IS, Class I, Div. 2, Group A, B, C, D
IS, Class I, Zone 2, Group IIC
25
25
