PROFIBUS
PA / FOUNDATION™ FIELDBUS
TRANSMITTER - PRetop 5350
®
• PROFIBUS
PA ver. 3.0
• FOUNDATION™ Fieldbus ver. ITK 4.6
• Automatic switch between protocols
• FISCO-certified
• Basic capability with F.F.
Application:
• Linearised temperature measurement with RTD or TC sensor.
• Difference, average or redundancy temperature measurement with RTD or TC
sensor.
• Linear resistance, potentiometer and bipolar mV measurement.
Technical characteristics:
• Bus transmitter with both PROFIBUS
communication. A unique switch function ensures automatic shift between
the two protocols.
®
• Set-up for PROFIBUS
PA can be done via Siemens Simatic
Melody / Harmony and Metso DNA software and for F
via Emerson DeltaV, Yokogawa CS 1000 / CS 3000, ABB Melody / Harmony
and Honeywell Experion software.
• The simulation mode function can be activated by way of a magnet.
• Polarity-independent bus connection.
• 24 bit A/D converter ensures high resolution.
®
• PROFIBUS
PA function blocks: 2 analogue.
• F
Fieldbus function blocks: 2 analogue and 1 PID.
OUNDATION™
• F
Fieldbus capability: Basic or LAS.
OUNDATION™
Mounting / installation:
• For DIN form B sensor head mounting. In non-hazardous areas the 5350 can
be mounted on a DIN rail with the PR fitting type 8421.
20
20
All manuals and user guides at all-guides.com
TM
®
PA and F
Fieldbus
OUNDATION
®
®
PDM
, ABB
Fieldbus
OUNDATION™
RTD to
bus communication
TC to
bus communication
Resistance to
bus communication
mV to
bus communication
Difference, redundancy or
average; RTD, TC or mV
-
+
-
+
-
+
-
+
or
