Safety instructions
Ex installation:
For safe installation of 5350 in a hazardous area, the following must be obser-
ved. The module must only be installed by qualified personnel who are fami-
liar with the national and international laws, directives and standards that
apply to this area.
Year of manufacture can be taken from the first two digits in the serial number.
The sensor circuit is not infallibly galvanically isolated from the input circuit.
However, the galvanic isolation between the circuits is capable of withstan-
ding a test voltage of 500 Vac during 1 minute.
The transmitter must be mounted in an enclosure in order to provide a degree
of ingress protection of at least IP20.
In explosive atmospheres caused by air / dust mixtures:
The transmitter may only be installed in a potentially explosive atmosphere cau-
sed by the presence of combustible dust when mounted in a metal enclosu-
re form B according to DIN 43729 that is providing a degree of ingress pro-
tection of at least IP 6X in accordance with EN 60529, that is suitable for the
application and is correctly installed.
Cable entries and blanking elements shall be used that are suitable for the
application and correctly installed.
For an ambient temperature ≥60°C, heat resistant cables shall be used with a
rating of at least 20 K above the ambient temperature.
Special Conditions for Safe Use - 5350A:
The transmitter shall be mounted in an enclosure providing a degree of ingress
protection of at least IP54 in accordance with EN 60529.
Provisions must be made to prevent the rated supply voltage being exceeded
by transient disturbances of more than 40%.
Special Conditions for Safe Use - 5350B:
If the enclosure in which the transmitter is mounted is made of aluminium and
installed in Zone 0, 1 or Zone 20, 21 or 22 it shall not contain by weight more
than 6% in total of magnesium and titanium.
The additional enclosure of the apparatus shall be designed and/or installed in
such a way that, even in the event of rare incidents, ignition sources due to
impact and friction sparks are excluded.
18
18
All manuals and user guides at all-guides.com
EC DECLARATION OF CONFORMITY
As manufacturer
PR electronics A/S
Lerbakken 10
DK-8410 Rønde
hereby declares that the following product:
Type: 5350
Name: PROFIBUS
Fieldbus transmitter
is in conformity with the following directives and standards:
EMC directive 2004/108/EC and later amendments
EN 61326-1 : 2006
For specification of the acceptable EMC performance level, refer to the
electrical specifications for the module.
The ATEX directive 94/9/EC and later amendments
EN 50014 : 1997, EN 50020 : 2002,
EN 60079-15 : 2003, EN 50284 : 1999,
EN 60079-27 : 2005
ATEX certificate: KEMA 03ATEX1011 X (5350A)
ATEX certificate: KEMA 02ATEX1318 (5350B)
Notified body
KEMA Quality B.V. (0344)
Utrechtseweg 310, 6812 AR Arnhem
P.O. Box 5185, 6802 ED Arnhem
The Netherlands
Rønde, 13 May 2008
®
PA / FOUNDATION™
Peter Rasmussen
Manufacturer's signature
19
19
