Rotel products are designed to comply with international
directives on the Restriction of Hazardous Substances
(RoHS) in electrical and electronic equipment and
the disposal of Waste Electrical and Electronic
Equipment (WEEE). The crossed wheelie bin symbol
indicates compliance and that the products must be
appropriately recycled or processed in accordance
with these directives.
Pin Assignments
Balanced Audio (3 pole XLR):
Pin 1: Ground / Screen
1
2
Pin 2: In phase / +ve / Hot
3
Pin 3: Out of phase / -ve / Cold
STANDBY
STANDBY
VIDEO 1
VIDEO 2
VIDEO 3
VIDEO 4
VIDEO 5
5V 2. 1 A
2CH
BYPASS
SUR +
DISPLAY
MUTE
USB
PC-USB
XLR
TUNER
CD
HDMI
3
VIDEO 6
VIDEO 7
PHONO
BT
