Anleitung_RT_OS_30_SPK1:_
GB

5. Before starting the equipment

Before you connect the equipment to the mains
supply make sure that the data on the rating plate
are identical to the mains data.
Always pull the power plug before making
adjustments to the equipment.
5.1 Installing the dust collector (Figure 2-3/Item 6)
The dust collector (6) must be connected to the
dust extractor connector (a).
The dust is extracted directly through the
grinding/sanding paper and the orbital disk and
into the dust collector.
To empty the duct collector, open it as shown in
Fig. 3 and carefully tap it to remove the debris.
5.2 Installing the dust extractor adapter
(Figure 4/Item 9)
Connect the dust extractor adapter (9) to the dust
extractor connector (a) as shown in Fig. 4 and
secure it by turning it. Connect the dust extractor
adapter to a suitable dust extraction system.
Important.
The use of the dust collector or a dust extraction
system is absolutely essential for safety reasons.
5.3 Securing sanding/grinding paper using a
Velcro fastening (Fig. 5)
Only use sanding/grinding paper of the
appropriate size and suitable perforations.
Place the sanding/grinding paper on the
oscillating plate (7) as shown in Fig. 5. Make
sure that the perforations in the sanding/grinding
paper line up with the oscillating plate.
5.4 Securing sanding/grinding paper using a
clamp (Fig. 6)
Only use sanding/grinding paper of the appropriate
size and suitable perforations.
Raise the lever (8) on the front of the orbital
sander slightly and detach it.
Insert the sanding/grinding paper as far as
possible into the open clamp and close the lever
again.
Place the sanding/grinding paper taut over the
orbital plate (7) and clamp it again using the
second lever (8) on the rear of the orbital sander.
Make sure that the perforations in the
sanding/grinding paper line up with the oscillating
plate.
10
04.11.2010
9:17 Uhr
Seite 10
6. Operation
6.1 Switching the machine on and off
(Fig. 7/Item 2)
To switch on:
Press the control switch (2).
Continuous operation:
Lock the control switch by pressing the locking
switch (4).
To switch off:
Press the control switch briefly and release it.
6.2 Speed control (Fig. 7/Item 3)
To pre-select the speed turn the knurled screw (3) on
the switch.
Plus direction:
Minus direction:
6.3 Working with the orbital grinder/sander
Place the whole surface area of the sanding disk
on the material.
Switch on the machine and move it with gentle
pressure over the workpiece completely circular
movements or moving it to and fro and up and
down.
Use a coarse paper for coarse sanding and a
finer paper for finish sanding. You can find the
best paper for the job by means of testing.
Important.
The dust generated when working with the machine
may be harmful.
Always wear goggles and a dust mask when
carrying out sanding/grinding work.
Everybody who uses the machine or enters the
workplace must wear a dust mask.
Do not eat, drink or smoke at the workplace.
Do not use the machine on paints which contain
lead.

7. Replacing the power cable

If the power cable for this equipment is damaged, it
must be replaced by the manufacturer or its after-
sales service or similarly trained personnel to avoid
danger.
Higher speed
Lower speed
