TRI-ARC
BLADE
®
The Tri-Arc
blade is suited only for thicker weeds and
pulpy stalks. When the blade becomes dull, it can be
turned over to extend the life of the blade.
Do not sharpen the Tri-Arc
CUTTING TECHNIQUE - BLADE
WARNING
Extreme care must be taken when using blades
to ensure safe operation.
Read the safety information for safe operation using the
blade, refer to Specific Safety.
Rules for Brushcutter and Blade Use earlier in this
manual.
Always hold brushcutter on your right side with both
hands when operating. Use a firm grip on both handles.
Maintain your grip and balance on both feet.
Position your self so that you will not be drawn off
balance by the kick back reaction of the cutting blade.
See Figures 9 - 10.
Avoid hot surfaces by always keeping the tool away
Q
from your body. (Proper operating position shown in
figure 9.)
Keep the brushcutter tilted toward the area being cut;
Q
this is the best cutting area.
The trimmer cuts when passing the unit from left to
Q
right. This will avoid throwing debris at the operator.
Avoid cutting in the dangerous area shown in
illustration.
Use the tip of string to do the cutting; do not force
Q
string head into uncut grass.
Wire and picket fences cause extra line wear, even
Q
breakage. Stone and brick walls, curbs, and wood
may wear line rapidly.
Avoid trees and shrubs. Tree bark, wood mouldings,
Q
siding, and fence posts can easily be damaged by
the string.
STARTING AND STOPPING
See Figures 12 - 14.
When starting the line trimmer for the first time or
when the battery voltage is low, it may be necessary to
manually start the string trimmer.
:$51,1*
Before attempting to start the product, ensure
the cutting attachment is in a safe position
where it cannot hit loose objects or yourself or
bystanders. Once the engine is running you
should exercise proper control over the product,
never leave it unattended.
FOR MANUAL START:
To start a cold engine:
DO NOT squeeze the throttle trigger until the engine
Q
IT
PT
NL
SV
DA
English (original instructions)
®
blade.
NO
FI
HU CS RU
starts and runs.
Lay the trimmer on a flat, level surface.
Q
PRIME - Press the primer bulb at least 7 times, so
Q
fuel is clearly visible.
SET the start lever to the START position.
Q
Ensure the 'Ignition switch' (item 6) is in the centre
Q
position.
PULL the recoil starter until the engine starts.
Q
Wait 6-10 seconds, then gently squeeze the trigger to
Q
run.
NOTE: Squeezing and releasing the throttle trigger
releases the start lever to the RUN position.
To start a warm engine:
Make sure the 'ignition switch' is in the centre
Q
position.
PULL the recoil starter until the engine starts.
Q
To stop the engine:
Press the 'ignition switch' (item 6) to the stop " O "
Q
position and the engine will stop.
FOR ELECTRIC START: RBC30SET - ONLY
MAKE SURE THE BATTERY HAS BEEN FULLY
CHARGED - SEE CHARGING BATTERY
To start a cold engine:
DO NOT squeeze the throttle trigger until the engine
Q
starts and runs.
Install the battery onto the unit as shown in figure 8.
Q
Lay the trimmer on a flat, level surface.
Q
PRIME - Press the primer bulb at least 7 times, so
Q
fuel is clearly visible.
SET the start lever (item 20) to the START position
Q
on the side of the carburettor.
PRESS the 'safety switch' (item 18) and the 'ignition
Q
switch' to position 3 (item 6) at the same time.
N.B. The safety switch is a rocker type switch and will
Q
automatically reset it's self once released.
N.B. The ignition switch is a 3 position switch.
Q
position 1 is 'off' ("0") position 2 is run, and position
3 ("I") is a rocker type switch which will automatically
reset it's self to position 2 once released.
RELEASE the 2 switches after engine starts - they
Q
will revert back to their resting place.
Wait 6-10 seconds, then squeeze the throttle trigger
Q
to run.
NOTE: Squeezing and releasing the throttle trigger
releases the start lever to the RUN position.
To start a warm engine:
Lay the trimmer on a flat, bare surface.
Q
PRESS the 'safety switch' (item 18) and the 'ignition
Q
switch' (Item 6) at the same time.
RELEASE the 2 switches after engine starts - they
Q
will revert back to their resting place.
FOR ELECTRIC START RBC30SBT - ONLY
