Figure 11
44. Trimmer line cut-off blade
Figure 14
45. Start position
46. Run position
Figure 15
47. Tri-arc Blade
Figure 16
48. Idle speed screw
Figure 17
19. Latch
Figure 18
19. Latch
49. Filter screen
50. Air filter cover
ASSEMBLY
UNPACKING
This product requires assembly.
Carefully remove the tool and any accessories from
Q
the box. Make sure that all items listed in the packing
list are included.
Inspect the tool carefully to make sure no breakage
Q
or damage occurred during shipping.
Do not discard the packing material until you have
Q
carefully inspected and satisfactorily operated the
tool.
If any parts are damaged or missing do not operate
Q
this product until the parts are replaced. Failure to
heed this warning could result in serious personal
injury.
WARNING:
Do not attempt to modify this product or create
accessories not recommended for use with this
product. Any such alteration or modification is
misuse and could result in a hazardous condition
leading to possible serious personal injury.
WARNING:
To prevent accidental starting that could cause
serious personal injury, always disconnect the
engine spark plug wire from the spark plug and
remove battery pack when assembling parts.
INSTALLING THE POWER HEAD SHAFT TO THE
ATTACHMENT
See Figure 2.
IT
PT
NL
SV
DA
English (original instructions)
NO
FI
HU CS RU
WARNING:
Never install, remove, or adjust any attachment
while power head is running. Failure to stop the
engine can cause serious personal injury.
The attachment connects to the power head shaft by
means of a coupler device.
Loosen the knob on the coupler of the power head
Q
shaft and remove the end cap from the attachment.
Push in the button located on the attachment shaft.
Q
Align the button with the guide recess on the power
head coupler and slide the two shafts together.
Rotate the attachment shaft until the button locks into
the positioning hole.
NOTE: If the button does not release completely in the
positioning hole, the shafts are not locked into place.
Slightly rotate from side to side until the button is locked
into place.
Tighten the knob securely.
Q
WARNING:
Be certain the knob is fully tightened before
operating equipment; check it periodically for
tightness during use to avoid serious personal
injury.
REMOVING THE ATTACHMENT FROM THE POWER
HEAD
For removing or changing the attachment:
Loosen the knob.
Q
Push in the button and twist the shafts to remove and
Q
separate ends.
ATTACHING THE HANGER CAP
See Figure 3.
There are two ways to hang your attachment for storage.
To use the hanger cap, push in the button and place
Q
the hanger cap over end of the lower end attachment
shaft. Slightly rotate the cap from side to side until the
button locks into place.
The secondary hole in the attachment shaft can be
Q
used for hanging purposes as well.
ATTACHING THE FRONT HANDLE
See Figure 4.
RBC30SET
Remove the bolt (33) and bracket (32) from the front
Q
handle (31).
Install the front handle (31) onto the top side of the
Q
drive shaft housing (27).
Note: The front handle (31) should tilt slightly
towards the operator when correctly fitted.
Place the bolt through the front handle and securely
Q
tighten them into the captive nuts on the bracket (32).
23
