Temperature tables
Measuring system Promass 80 (compact version)
at T = 50 °C
a
Promass F DN 8...40
Promass F DN 50
Promass F DN 80...150
Promass I DN 8...25, 15 FB
Promass I DN 40...50, 25 FB, 40 FB
Promass M DN 8...15
Promass M DN 25...40
Promass M DN 50
Promass M DN 80
Promass H DN 8
Promass H DN 15...50
Promass E DN 8...15
Promass E DN 25...50
at T = 60 °C
a
Promass A DN 1...4
Promass F DN 8...40
Promass F DN 50
Promass F DN 80...150
Promass F (HT) DN 25, 50, 80
Promass I DN 8...25, 15 FB
Promass I DN 40...50, 25 FB, 40 FB
Promass M DN 8...15
Promass M DN 25...40
Promass M DN 50
Promass M DN 80
Promass H DN 8
Promass H DN 15...50
Promass E DN 8...50
*) The maximum permissible fluid temperatures apply only when the transmitter is installed in such a way that
it is not above the sensor and heat can be removed freely by convection in all directions.
The minimum medium temperature is –50 °C (Promass F, M, A, H, I), resp. –40 °C
(Promass E).
Max. medium temperature [°C] in
T6 T5 T4
85 °C 100 °C 135 °C
55 95 130 150 (170*)
60 95 130 150 (170*)
60 75 110 150 (170*)
60 95 130
70 85 120
55 95 130
60 95 130
65 95 130
65 80 110
50 65 100
60 75 115
– 100 125
50 100 125
Max. medium temperature [°C] in
T6 T5 T4
85 °C 100 °C 135 °C
60 95 130
55 95 100
60 95 100
60 75 100
65 80 110*
60 95 130
70 85 120
55 95 100
60 95 100
65 95 100
65 80 100
50 65 100
60 75 115
– 100 125
PROline Promass 80
T3 T2 T1
200 °C 300 °C 450 °C
200* 200*
200* 200*
200* 200*
150 150 150
150 150 150
150 150 150
150 150 150
150 150 150
150 150 150
160 200 200
180 200 200
125 125 125
125 125 125
T3 T2 T1
200 °C 300 °C 450 °C
150 200 200
100 100 100
100 100 100
100 100 100
175* 265* 350*
150* 150* 150*
150* 150* 150*
100 100 100
100 100 100
100 100 100
100 100 100
160 200* 200*
180* 200* 200*
125 125 125
