Installing the battery pack

1. You need to insert the battery pack in the open section
for the battery. Use the strap provided to place on top of the
battery and then use the 2 retaining clips to secure the battery.

Turning on the power

Turn on transmitter first and then turn on receiver.
Turn on the transmitter switch and the LED battery indicator will light up.
If it blinks or does not light up, check the polarities and battery power.
If the battery power is low, replace the batteries with new ones.
Turn on the receiver. The automatic set-up of the factory set speed control should
have been completed. If you experience any problems with the speed control settings refer to the Electronic
Speed Control Section for correct setup information.

Turning off the power

Turn off receiver first and then turn off transmitter.
If you switch off the transmitter first before the R/C car, you may lose control of the R/C car.
•
Turn off the receiver switch.
•
Turn off the transmitter switch.
•
Disconnect the battery connector from the speed control connector.
Make sure to always turn off the power in this order (opposite order of turning on the power). If you turn off the power in the wrong order, the
vehicle may run out of control and this can be very dangerous.
Always disconnect the battery connector from the speed control connector after driving.

Trim Setup

If the front tyres are not pointing straight forward with the transmitter on, adjust the steering trim. Then if needed make fine adjustments with the
steering trim whilst driving the vehicle.
If wheels point left, turn clockwise
All manuals and user guides at all-guides.com
2.
plug into the speed controller plug noting correct polarity. Red to
red, black to black.
If wheels point right, turn anti-clockwise.
6
Once fastened and secured please connect the battery
If they point straight no adjustment
required.
