When you want to manually install a new roll of paper while your machine is turned off, follow the
steps shown below:
1.
Pull the print head release lever toward you (to the head-up position). (Refer to the drawing on page 54.)
2.
Correctly place the new paper roll into the paper bed.
3.
Insert the paper end into the printer until it comes out of the printer.
4.
Return the print head release lever to its original position.
Removing the paper roll
When a red dye appears on the paper roll, it is time to replace the existing paper roll. Replace the paper roll
with new one. If you plan not to use your register for an extended period of time, remove the paper roll, and
store it in the appropriate place.
Precaution: Be very careful for the manual cutter mounted on the printer cover when removing and
replacing the cover, so as not to hurt yourself.
When the take-up spool is not used:
When the take-up spool is used:
56
All manuals and user guides at all-guides.com
1.
Remove the printer cover.
2.
Cut the paper behind the printer and near the paper roll.
3.
á
Press the
key until the paper remaining in the printer comes out
completely.
4.
Remove the paper roll from the paper bed.
Do not pull the paper through the printer.
1.
Remove the printer cover.
2.
á
Press the
key to advance the journal paper until its printed part is out of
the way.
3.
Cut the paper and remove the take-up spool.
4.
Cut the paper behind the printer and near the paper roll.
5.
á
Press the
key until the paper remaining in the printer comes out
completely.
6.
Remove the paper roll from the paper bed.
Do not pull the paper through the printer.
7.
Remove the outer side of the take-up spool as shown
on the left.
8.
Remove the printed journal roll from the take-up spool.
