OPERATION

Changing Temperature Unit of Measure

Use the following procedure to change the temperature unit
of measure between Fahrenheit and Celsius. This procedure
requires access to password-protected screens and should be
performed by authorized personnel only.
1. From the Categories screen, touch
• A password keypad will appear on the touchscreen.
2. Input the password "12345" , and touch
• The Settings screen will appear on the touchscreen.
Touch desired icon to
view/edit/create
corresponding setting.
Touch to return to
Categories screen.
Settings Screen
3. Touch OPTIONS on the Settings screen. The Options
screen appears.
4. Touch and drag the slider below the "°F" and "°C" on the
Options screen to toggle the unit of measure between
Fahrenheit and Celsius.
Drag slider between
"ºC" and "ºF" to
toggle setting.
Touch desired icon to
view/edit/create
corresponding setting.
Touch to return to
Settings screen.
Options Screen
5. When finished changing the unit of measure, touch
twice to return to the Categories screen.

Importing from a USB Drive

Use the following procedure to import pre-programmed recipes
or firmware updates from an external USB drive. This procedure
requires access to password-protected screens and should be
performed by authorized personnel only.
.
NOTE: USB drive must have a capacity of 64 GB or less.
1. Slide the cover away from the USB port next to the
.
2. From any screen, touch
3. Input the password "12345" , and touch
4. Touch USB FUNCTIONS on the Settings screen. The USB
IMPORTANT NOTE
For the following USB functions, the oven must be cool and
in an idle state: CONFIG IMPORT, SOFTWARE UPDATE UI,
and SOFTWARE UPDATE RB.
5. Touch the desired function to begin the corresponding
6. When the import is complete:
14
touchscreen, and insert the USB drive into the port.
• A password keypad will appear on the touchscreen.
• The Settings screen will appear on the touchscreen.
Functions screen appears.
Touch desired
function.
Touch to return to
Settings screen.
USB Functions Screen
import.
• Select the import file from the list that appears.
• A screen will appear to indicate that the import is in
progress.
• For USB functions RECIPE EXPORT, RECIPE IMPORT,
and CONFIG IMPORT—The touch screen will return to
the USB Functions screen. Remove the USB drive from
the USB port, and slide the USB cover over the port.
• For USB functions SOFTWARE UPDATE UI and
SOFTWARE UPDATE RB—The oven will restart. Do
not remove the USB drive from the USB port until the
touchscreen reads "Remove the USB." Slide the USB
cover over the port.
English
.
.
OVMILOM-1022
