Truma iNet X Panel / Truma iNet X Pro Panel
Use a Phillips-tip screwdriver (Fig� 7-1) to turn the
fastening screw in a clockwise direction until the
installation clip faces completely downward� You
will no longer see the clip in the inspection window
(Fig� 7-2)�
Tighten the fastening screw finger tight (maximum
torque 0�4 Nm)� The control panel is now fixed in
place in the mounting frame�
Fig� 7
47000-00082 · 01 · 11/2021
2
1
Attach the button plate (Fig� 8-2) onto the frame of
the control panel (Fig� 8-1)�
Fig� 8
Installation
1
2
EN 21
