Diamond RM32A Notice D'emploi page 39

LISTE DE PIECES DETACHEES RM42A (P42/X) 2012
Pos. Code
1
S39SC54027
2
S32DL54003
3
S47IE54007
4
S47SR54003
5
S61IE54026
5.1
A90SU78010
6
A90BI54002
7
A98DL54002
8
S79BL54001
9
S51RL54019
10
S51RL54020
11
A87MR55003
12
A90KI78001
13
S63CD54002
14
S63EC54004
15
S75CD54008
16
S75EC54007
17
S43RA54005
18
S43RA54005
19
S61RL54003
20
S63CD54005
21
S63EC54002
22
S75CD54004
23
S75EC54004
Description
Involucro Roll Mach RM 42 A Release 2012
Coperchio Roll Mach RM 42 A Release 2012
Scivolo inferiore Roll Mach RM 42 A Release 2011
Scivolo superiore Roll Mach RM 42 A
Protezione inferiore raggiata Diamond RM 42 A
Protezione superiore RM 42 A Release 2012
Gruppo bilancia P40-P40A
Bilancino Roll Mach RM 42
Contropeso bilancino RM 42 Release 2011
Gruppo rulli inferiore Roll Mach RM 42 A Release
2012
Gruppo rulli superiore Roll Mach RM 42 A Release
2012
Motore S71B4 0,37 kW 230V 50 Hz B5
Cinghia Ø 8x784 Roll Mach
Albero inferiore cilindrico P40-P40A-P40T-P40TA-
RM42A
Albero inferiore
P40TA-RM42A
Rullo inferiore cilindrico P40-P40A-P40T-P40TA-
RM42A
Rullo inferiore eccentrico P40-P40A-P40T-P40TA-
RM42A
Raschiapasta anteriore P40-P40A-P40T-P40TA-
RM42A
Raschiapasta posteriore P40-P40A-P40T-P40TA-
RM42A
Asta Inox Ø5x438 mm
Albero superiore
P40TA-RM42A
Albero superiore
P40TA-RM42A
Rullo superiore cilindrico P40-P40A-P40T-P40TA-
RM42A
Rullo superiore
P40TA-RM42A
eccentrico P40-P40A-P40T-
cilindrico P40-P40A-P40T-
eccentrico P40-P40A-P40T-
eccentrico P40-P40A-P40T-
Q.ty
1
1
1
1
1
1
1
1
1
1
1
1
2
1
1
1
1
1
1
1
1
1
1
1
