Installation
5.2 Installation (Qualified specialist)
5.2.1 Installation tip concrete pool
Concrete pool with foil
Stainless steel panel
Fig. 3
Tiled concrete pool
Stainless steel panel
Fig. 4
20 EN
Support ring
Suction panel
Support ring
Suction panel
Handle
Foil
Concrete
Main housing
Seal
WG23.140.035-2-P
Handle
Tiles
Concrete
Seal
WG23.140.036-2-P
Main housing
