STEINEL PROFESSIONAL IR Quattro COM1-WR Manuel page 21

Functions – Settings by Potentiometer
COM1-WR / COM1-24 / COM2-24 / DIM-24
Potentiometer
Light level setting
The chosen response threshold
can be adjusted from approx.
10 – 1000 lux / 1 – 100 fc.
Examples of use
Night-time mode, minimum setting approx. 10 lux / 1 fc
Corridors, foyers
Stairs, escalators, moving walkways
Restrooms, dining areas
Classrooms, sales fl oors, gymnasiums
Individual offi ces, conference and meeting rooms
Laboratories, precision work areas
Daylight mode
Note: Depending on the site of installation, the setting may need to be corrected by 1 – 2 marks on the scale.
Brightness is measured directly at the sensor.
Potentiometer
Occupancy time delay setting
The occupancy time delay
setting for switching output 1 is
adjustable from a minimum of
Pulse mode (except DIM)
If the dial is set to
terclockwise), the unit is in pulse
mode, i.e. the output is switched
'ON' for approx. 2 sec. Afterwards,
IQ mode
Turned fully clockwise: The stay-
'ON' time is self-learning and
adjusts dynamically to user
IR Quattro COM-WR_USA_03-07-13_ENU-FRA.indd 21 R Quattro COM-WR_USA_03-07-13_ENU-FRA.indd 21
Control dial turned fully clockwise:
MAX daylight mode
30 seconds to a maximum of
30 minutes.
(fully coun- the sensor does not respond to
movement for approx. 8 sec. For
use with a time delay relay.
behaviour. The optimum time
cycle is determined by means of
a learning algorithm.
Control dial turned fully
counterclockwise:
MIN night-time operation
The shortest time is 5 min.,
the longest 20 min.
- 21 -
Light level settings
min
1
2
3
4
5
>=6
max
