Sensor DIP Switch Settings
COM1-WR / COM1-24 / COM2-24 / DIM-24
DIP 1
Normal mode / Test mode (NORM / TEST)
Test mode has priority over all
other settings on the presence
detector and serves the purpose
of checking for proper working
order as well for testing the
detection zone. Irrespective
DIP 2
Manual ON mode (MAN) / Automatic mode (AUTO)
Manual ON mode: (MAN)
The light now only switches
'OFF' automatically. Light is
Automatic mode: (AUTO)
The light automatically switches
'ON' and 'OFF' in relation to
occupancy and daylight contri-
bution. Light can be switched
'ON' and 'OFF' manually at any
DIP 3
Momentary / Maintained switch option
Tells the sensor how to interpret
the incoming maintained or
momentary switching signal.
Assigning external (momentary)
buttons/(maintained) switches
allows you to operate the
DIP 4
'ON' only / 'ON'&'OFF' manual switching
In the 'ON'-'OFF' setting, the light
can be switched 'ON' and 'OFF'
manually at any time (except in
DIM-24
DIP 5
Constant light level DIM control option
Provides a constant level of
brightness. Detector measures
the level of daylight and acti-
vates sufficient artificial light to
IR Quattro COM-WR_USA_03-07-13_ENU-FRA.indd 20 R Quattro COM-WR_USA_03-07-13_ENU-FRA.indd 20
of ambient light level, the pres-
ence detector activates the light
to stay 'ON' for approx. 8 sec. in
response to movement in the
room (blue LED flashes when
movement is detected). All user-
switched 'ON' manually by the
occupant and and stays 'ON' for
time. When switched 'OFF' man-
ually this temporarily interrupts
the automatic 'ON' function as
long as the room is occupied.
Once the room is no longer
detector as a manual on unit
or override it manually at any
time. When using the DIM-24
power module and a momentary
switch, light can be dimmed
manually by pressing and hold-
pulse mode: no manual 'OFF'). In
the 'ON' setting, light can no lon-
ger be switched 'OFF' manually.
achieve the required level of
brightness. As daylight changes,
the electric light is adjusted
accordingly. In addition to the
- 20 -
selected potentiometer settings
apply in normal mode. The pres-
ence detector can also be set by
means of the blue LED without
any load connected.
the time setting of the sensor.
occupied and the time delay
of the sensor has elapsed the
sensor will return to the auto-
matic 'ON' function.
ing the momentary switch
until the desired light level is
achieved. Maximum wire lenght
between sensor and switch
<50 m / 164 ft.
The stay-'ON' time starts from
the beginning again each time
the button is pressed.
daylight component, electric
light is also switched 'ON' and
'OFF' in relation to whether or
not persons are present.
