Channel Plan Editor - Promax RM-026 Manuel

Config: This menu allows to edit Channel plans, this option also can be
selected by clicking on the channel plan icon:
This option allows to add channel files (Add Channel File) by
specifying the archives which contain the new channel plan in order
to add it in the channel plan library.
These archives show the extension (.ch8).
UpGrade: Allows to upgrade the PROMAX instrument main software. This
option also can be selected through the upgrade icon:
This option allows to add upgrade files (Add Upgrade File) by
specifying the archives which contain the new upgrades.
These archives show the extension (.p26).

2.2 Channel plan editor

This tool allows to modify the instrument channel plans. To accede to it select the
Config option in the main menu bar and then click on the Promax Channel Plan
option or directly from the main window, click on the Channel plan icon.
Page 6
RM-026 PROMAX instruments control software
Figure 2.- RM-026 main window
.
.
11/2006
