EN
Rev.1 29/07/2021
Pag.40
The submenus of the USER MENU (the only one accessible for the end user) are the following:
Menu STOVE STATUS
In this menu you can check the correct functioning of the most important components of the stove. Here is a list of real data of the
stove useful for service during inspection.
To go to the second screen, press key 1.
From the first screen it is possible to activate the initial loading of the auger by pressing key 2.
The Screw Status value will become 1.
The initial load will stop automatically after a pre-set time, to stop it first press key 2.
Repeat the operation several times until you see the pellet fall into the firepot.
It is possible to do this operation only if the stove is in FINAL CLEANING phase or OFF.
Use and maintenance manual R 1000 Pro
• Menu STOVE STATUS
• Menu SET TEMPER. ROOM
• Menu SET POWER
• Menu CLOCK
• Menu TIMER
• Menu LANGUAGE
• Menu COMFORT CLIMA
• Modalità SILENCE
• Modalità SELF CONTROL SYSTEM
• Menu VIEW SETTINGS
• Menu VIEW WORKING HOURS
• Menu SET DRAUGH/PELLET
Speed inlet flow
Rpm smoke fan
Smokes temperature
Screw status
Screw ON
RDS current reading RDS (m/s)
RPM current smoke extractor speed (rpm)
Smokes temperature (°C)
Screw status
SET
Set value RDS (m/s)
DF
Cold probe temperature RDS (°C)
DR
Hot probe temperature RDS
SK
Electronic board temperature (°C
(°C)
