Dimplex AC3N Instructions page 5

AC Air Curtains
Models : AC3N, AC45N, AC6N, AC3RN & AC6RN
IMPORTANT: THESE INSTRUCTIONS SHOULD BE READ CAREFULLY
IMPORTANT SAFETY ADVICE
DO NOT COVER OR OBSTRUCT the air inlet or outlet grille.
ENSURE THE APPLIANCE IS EARTHED.
Do not use this heater in areas where excessive dust exists.
This heater must not be located immediately above or below a fi xed socket outlet or connection box.
Always disconnect supply before working on the product.
This product should be mounted safely to solid wall or ceiling surfaces only.
Ensure the supply cables are of adequate current carrying capacity and are protected by a suitable fuse.
If the appliance is mounted in a toilet or washroom, the appliance should be mounted such that no
part of it can be touched by a person using a fi xed bath or shower.
If the appliance is mounted in a toilet or washroom an isolating switch must be provided outside the
washroom adjacent to the entrance door.
This appliance can be used by children aged from 8 years and above and persons with reduced
physical, sensory or mental capabilities or lack of experience and knowledge if they have been given
supervision or instruction concerning use of the appliance in a safe way and understand the hazards
involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made
by children without supervision.
Children of less than 3 years should be kept away unless continuously supervised. Children aged
from 3 years and less than 8 years shall only switch on/off the appliance provided that it has been
placed or installed in its intended normal operating position and they have been given supervision
or instruction concerning use of the appliance in a safe way and understand the hazards involved.
Children aged from 3 years and less than 8 years shall not plug in, regulate and clean the appliance
or perform user maintenance.
CAUTION — Some parts of this product can become very hot and cause burns. Particular
attention has to be given where children and vulnerable people are present.
This heater is not equipped with a device to control the room temperature. Do not use this heater in
small rooms when they are occupied by persons not capable of leaving the room on their own, unless
constant supervision is provided.
ATTENTION: IN ORDER TO
AVOID OVERHEATING DO
NOT COVER.
Electrical
The installation of this appliance should be carried out by a
competent electrician and be in accordance with the current IEE
wiring regulations.
Fixing Positions
This appliance may be either wall-mounted or fi xed to a ceiling -
see Fig. 2 for various fi xing positions and 'Installation' see section
below, for details on fi xing. Heaters may be mounted end to end
for wide doorways.
Installation
Using the wall mounting bracket as a guide (see 'a' in Fig. 3) mark
off the hole positions on the wall or ceiling (see 'B' in Fig. 1). A
minimum height of 1.8 metres is required from fl oor to bracket.
Fix the bracket in position by following steps as described under
the heading 'Wall or Ceiling Mounting'.
AND RETAINED FOR FUTURE REFERENCE
- 1 -
Wall or Ceiling Mounting
Solid brick or concrete block walls must be drilled and plugged
(using a spirit level as a guide ensure bracket is level), due to
different types of wall constructions fi xings are not included, ensure
the correct fi xings are used. The plug must be located in the solid
part of the wall, not just in the plaster layer.
For panelled internal walls or ceilings, it is best to locate the
studding, position the heater fi xing bracket accordingly and use
screws supplied. If it is not possible to locate the studding, use
type M5 Rawlplug inserts, making the 10mm holes with a drill
rather than a bradawl or a screwdriver.
Locate the heater on the mounting bracket ensuring that the pozi-
head screws are fully engaged in the slots of the bracket.
It is important that the serrated metal washer (a) is located between
the heater holding bracket (b) and the wall mounting bracket (c).
Adjust heater to the required angle then fi rmly tighten the fi xing
screw (d) inside the endcap (e) using a cross-head screwdriver
(f) as shown in Fig. 4.
Electrical connection
Release the screws at either end of the air-outlet grille (see Fig.
5) to gain access to the terminals for connection of the supply
cable - see Fig. 6.
UK
