Assembling the cabin

ATTENTION!
The cabin is designed for both "right-hand" and "left-hand" assembly.
Note the floor plans for this on Page 9 and Page 10.
Note illustrations from page 15 onwards.
The procedure described below is for "right-hand" assembly.
Changes for "left-hand" assembly - see Seite 11.

3.1. Assembling the base frame

With a hammer, carefully drive in the plastic dovetail keys on both corners of the
base frame until they are flush with the groove of the element.

3.2. Assembling the cabin walls

Start assembly by screwing the wall elements W2 and W3 to the corner post.
Mount the spacer strips (2090x40x55) on the corner posts.
Make sure the ventilation element is correctly positioned. The other wall elements
are connected tongue and groove and are screwed together.
Now move the sauna to its final position and check the right angles (see tip on
page 4).
Screw the "corner post with multiclip and groove for glass" to the wall element
W1. Mount the "cover board with multiclip" on the corner post.
Screw the "cover board with groove for glass" to the wall element W6.

3.3. Assembling the glass elements

Note that when installing the glass element "glass with holes drilled for
door hinges", you are defining the direction in which the door will open.
The bottom drill hole for the door hinge is 263 mm high.
Place the aluminium U-profile flush on the glass elements and insert the glass
elements into the groove provided.
Mount the strip over the glass and screw it diagonally to the corner post and the
cover strip.
Then mount the third glass element.
Finally, fit the roof frame strips and screw them to the wall elements. Observe
the cable outlets.
