Installation instructions, only for experts
No. of
Name
items
Glass front elements
1 Black glass front element 1x 45° - right
1 Black glass front element 1x 45° - left
1 Black glass front element 1x 45° - right
1 Black glass front element 1x 45° - left
1 Glass door
1 Glass element with hole for door hinges
2 Glass element
Roof elements
1 Black roof element
1 Black roof element
1 Cover strip for roof element
1 Cover strip for roof element
Interior Lindea decor
3 Lindea decor element
2 Lindea decor element
1 Lindea decor element with cut-out for exhaust air
2 Lindea decor element, roof
1 Lindea decor element, roof, with cover for sensor
1 Lime wood cover over glass (short side)
Interior fittings
1 Sauna bench with adjustable head piece
1 Sauna bench
1 Sauna bench
1 Sauna bench
1 Bench foot - lime wood
4 Bench support slats
1 Bench support slat
1 Floor grid
p. 7/32
Dimensions in mm
2035x85x55
2035x85x55
718x85x55
718x85x55
1975x628x8
2006x680x8
2006x680x8
2100x597x70
2100x840x70
2020x110x15
688x110x15
2020x656x40
2020x633x40
2020x633x40
1282x633x40
1282x633x40
633x40x40
1900x620x130
1200x620x130
1280x620x130
1280x350x90
620x445x60
570x40x40
965x40x40
600x270x40
