Installation instructions, only for experts

1.4. Parts list

No. of
Name
items
Base frame
1 Black floor frame with cut-out - right
1 Black floor frame with cut-out - left
1 Black floor frame
1 Black floor frame
Wall elements
2 Black wall element W2/W5
2 Black electrical element (2 cable ducts) W1/W6
1 Black electrical element (1 cable duct) W4
1 Black ventilation element
6 Extra tongue and groove boards
2 Black spacer strips
2 Roof frame strip
1 Roof frame strip
1 Roof frame strip
1 Roof frame strip
Corner posts
1 Black corner post
1 Corner post for glass element with multiclip and
groove for glass - right
1 Corner post for glass element with multiclip and
groove for glass - left
1 Cover board for corner post with multiclip - right
1 Cover board for corner post with multiclip - left
1 Cover board with groove for glass - right
1 Cover board with groove for glass - left
p. 6/32
Dimensions in mm
1382x40x80
1382x40x80
2100x40x80
718x40x80
1995x663x70
1995x663x70
1995x663x70
1995x663x70
663x55x15
2090x55x40
1990x40x20
1382x40x20
2100x55x20
1382x55x20
1975x70x70
2035x110x55
2035x110x55
2125x150x55
2125x150x55
2125x150x30
2125x150x30
