Installation instructions, only for experts
No. of
Name
items
Exterior Lindea decor
1 Lindea exterior decor element
1 Lindea exterior decor element
1 Lindea exterior decor element
1 Lindea exterior decor element
1 Lindea exterior decor element
1 Lindea exterior decor element
1 Lindea exterior decor element
1 Lindea exterior decor element
Accessories
1 Aluminium U strips
1 Aluminium U strip 1x 45° - right
1 Aluminium U strip 1x 45° - right
1 Aluminium U strip 1x 45° - left
1 Aluminium U strip 1x 45° - left
1 Silicone glass-glass seal WRU-60, 2m
1 LED strip, black
2 LED RGBW
1 Ventilation slide
1 Thermo-lime wood door handle set
1 2 door hinges 8653-02
1 Door magnet, sleeve plate
1 Silicone cable 4m - 5 x 2.5 mm²
1
Assembly material
1 Assembly instructions
p. 8/32
Dimensions in mm
2090x790x40
1950x745x40
130x802x40
2090x755x40
815x130x40
633x130x40
745x130x40
766x130x40
670x12x10
680x12x10
672x12x10
680x12x10
672x12x10
1890x30x35
1890x21x17
520x140x15
