Home Screen

When the Meter Screen is open, press the MENU button to open
the Home Screen.
Repeat playback status
1
An icon appears when the repeat playback function is on.
(See "Repeat playback function" on page 40)
Song format
2
This shows the current song file format.
44.1kHz, 16bit
44.1kHz, 24bit
48kHz, 16bit
48kHz, 24bit
NOTE
If no song is loaded, the operation format of the unit will be
shown like or .
Automatic punch in/out function on/off status
3
The icon appears when the automatic punch in/out
function is on. (See "Automatic punch in/out function" on
page 41)
SD card present status
4
When an SD card is loaded, the
When an SD card is protected, the
Since system files cannot be updated when the
appears, automatic punch in/out settings will not be retained
and previously loaded songs will not be loaded when the
unit is turned on again.
USB connection status
5
During USB connection, the
Song name
6
This shows the name of the current song.
If a song is protected, an
(See "Protecting/unprotecting songs" on page 34)
If a song has unsaved marks, an
file name. (See "Adding marks" on page 45)
Transport status
7
This icon shows the recorder operation status.
Indicator Meaning
Stopped at the beginning of the file
8
Paused
9
Recording
0
Playback
7
Playback position
8
The current playback position is shown by a bar.
Automatic punch in/out point setting status
9
When the automatic punch in/out function is on, these show
the status of automatic punch in/out point setting.
Punch in point
Punch out point
icon appears.
icon appears.
icon
icon appears.
icon appears before the file name.
icon appears before the
2 – Names and Functions of Parts
Remaining time
0
The remaining time available for recording on the SD card is
shown (in hours: minutes: seconds).
NOTE
The remaining recordable time on an SD card depends on
the number of recording channels and SD card capacity.
Built-in effect status
q
When a built-in effect is on, the number of the effect in use is
shown.
When the built-in effect is off, the
"Using the built-in effects" on page 38)
Recorder time counter
w
This shows the elapsed time from the beginning of the song.
Mark indicators
e
An icon is shown at each mark.
Song length
r
This shows the length of the current song (in hours: minutes:
seconds).
Function button functions
t
This shows the functions assigned to the function button on
the Home Screen.
i F1
button: This opens the Meter Screen.
i F2
button: This turns the repeat playback function
i F3
button: This returns to the state before the
i F3 button: This restores the state after the previous
i F4 button: This turns the built-in effect on/off.
i F4
button: This adds/deletes marks.
NOTE
i The F3 button
those operations are possible.
i Set the F4 button function on the KEY FUNCTION screen. (See
"Using mark functions" on page 45)
icon appears. (See
on/off.
previous operation.
operation.
and indicators appear when
