Before and during use, we recommend that you make the necessary arrangements for a safe rescue, should this be required.
This equipment must only be used by trained, competent and healthy persons, or under the supervision of a trained and competent
person. Warning! Certain medical conditions may affect user safety; if in doubt, consult your doctor.
Before each use, check:
The effectiveness of this anchor system depends on proper sizing of the safety
components, namely:
1
2
1: blocking half-moons and 3: blocking cone
The dimension opposite must be checked before each use: if the size is smaller, have
your equipment checked or discontinue use.
Also check before each use: that there is no sign of deformation or oxidation on any
IN-LOCK component. Pay particular attention to the anchorage ring and the crimping
3
on the components (on the blockage cone, the half-moons, placement indicator and the
O
anchorage ring). Check that the main cable is not cut or deformed. If there is any doubt,
> 20.6 mm
the equipment must not be used until a qualified individual has carried out a complete
check.
Do not remove, add or replace any component of the product.
Chemical products: do not use the device in the event of contact with chemical products, solvents or fuels which could affect its
operation.
TECHNICAL SPECIFICATIONS:
Stainless steel and aluminium. Cable: Galvanised steel: diam. 6 mm. Weight: 150 g +/- 10 g. R>12 kN.
KRATOS SAFETY certifies that this equipment has been tested in accordance with the standard EN 795:2012 Type B.
COMPATIBILITY FOR USE:
An anchorage point must be used in a fall arrest system as defined in the product's factsheet (see RN 363) in order to guarantee a
maximum arrest force of 6 kN on the user. A fall arrester harness (EN361) is the only body support device permitted for use. It may
be dangerous to create your own fall arrest system in which each safety function may interfere with another safety function. As
such, before each use, refer to the recommendations for use for each of the system's components.
INSPECTIONS:
The recommended service life of the equipment is 10 years (in accordance with the annual examination by a competent person
authorized by KRATOS SAFETY), but it may be increased or reduced according to use and/or the results of the annual
inspections. The equipment should be inspected if there is any doubt, or following a fall and at least annually, by the manufacturer
or a competent person authorised by the manufacturer to check its strength and hence the user's safety. The product's factsheet must
be completed (in writing) after each check; the inspection date and the date of the next inspection must be indicated on the
factsheet, it is also advisable to specify the date of the next inspection on the product.
MAINTENANCE AND STORAGE: (these instructions must be strictly observed)
During transportation, keep the equipment away from any cutting edges and in its packaging. Clean with water, wipe with a cloth
and hang in a ventilated room to dry naturally, ensuring that it is away from any direct light or source of heat; the same applies for
elements that may have got wet during use. The device must be stored in a cool, dry and ventilated room, and in its packaging.
5
