Identification Des Pièces - Backyard Discovery CEDAR POINT Mode D'emploi

Identification des pi è ces
Composants en bois
(NON À L'ÉCHELLE)
E1 - VERTICAL INFÉRIEUR - W4L07312
(1)
1 3/8"x3 3/8"x42 3/4" (36x86x1087)
E2 - VERTICAL SUPÉRIEUR - W4L07308
(1)
1 3/8"x3 3/8"x38 7/8" (36x86x989)
(1) E3 - VERTICAL INFÉRIEUR - W2A02022
1 3/8"x3 3/8"x42 3/4" (36x86x1087)
E4 - VERTICAL SUPÉRIEUR - W4L07298
(1)
1 3/8"x3 3/8"x38 7/8" (36x86x989)
E5 - VERTICAL INFÉRIEUR - W4L07248
(2)
1 3/8"x3 3/8"x42 3/4" (36x86x1087)
E6 - VERTICAL SUPÉRIEUR - W4L07289
(1)
1 3/8"x3 3/8"x38 7/8" (36x86x989)
E9 - SUPÉRIEUR ANGLE ENTRETOISE - W4L07239
(2)
1 3/8"x3 3/8"x34 1/8" (36x86x866)
E10 - INFÉRIEUR ANGLE ENTRETOISE - W4L07241
(2)
1 3/8"x3 3/8"x46" (36x86x1168)
E11 - VERTICAL SUPÉRIEUR - W4L07307
(1)
1 3/8"x3 3/8"x38 7/8" (36x86x989)
G1 - SUPPORT FIN - W4L07240
(1)
1"x5 1/4"x42 7/8" (24x134x1090)
H1 - RAIL DE PLANCHER - W4L07297
(1)
1"x3 3/8"x36 1/8" (24x86x919)
H2 - RAIL DE PLANCHER - W4L07251
(1)
1"x3 3/8"x36 1/8" (24x86x919)
H3 - SUPPORT SUPÉRIEURE - W4L07255
(1)
1"x3 3/8"x36 1/8" (24x86x919)
H4 - RAIL MURAL - W4L07267
(1)
1"x3 3/8"x35 3/8" (24x86x898)
H5 - RENFORT DE TERRASSE - W4L07273
(4)
1"x3 3/8"x18 3/4" (24x86x476)
H6 - RENFORT DE TERRASSE - W4L07276
(2)
1"x3 3/8"x13 3/4" (24x86x350)
H7 - PLANCHE DE SOL DE BANC - W4L07282
(2)
1"x3 3/8"x16 7/8" (24x86x430)
