HYDAC FILTER SYSTEMS CS 1000 Notice page 13

CS 13xx Menüstruktur / Menu structure / Structure de menus
PowerUp Menu
MODE Measuring mode
mTIME Measuring time
pPRTC Pump Protection
ADRESS Bus address
FREEZE Display Freeze
DFAULT Factory setting
CALIB Select calibration
CANCEL Cancel
SAVE Save changes and exit PowerUp
menu
CODE For internal use only
Measuring Menu
DSPLAY Display
SWtOUT Switching Output
ANaOUT Analog output
CANCEL Discard changes and exit
SAVE Discard changes and exit
M1 Mode 1
M2 Mode 2
M3 Mode 3
M4 Mode 4
SINGLE Single mode
60
0
HECOM HECOM3b address
IP Reserved
MODBUS Reserved
OFF off
MANUAL Manual
TIMOUT Automatic
ISoSAE ISO99/SAE
ISoNAS ISO87/NAS
ISO ISO code
NAS 2 NAS 2 µm
NAS 5 NAS 5 µm
NAS 15 NAS 15 µm
NAS 25 NAS 25 µm
NAsMAX NAS maximum
FLOW Flow range
ANaOUT Analog output
DRIVE LED current in %
TEMP C Temperature in °C
TEMP F Temperature in °F
M1 Mode 1
NO SET
M2 Mode 2
SP1
M3 Mode 3
MEAsCH
TARGET
M4 Mode 4
MEAsCH
TARGET
RSTART
CYCLE
SINGLE Single mode
A
Switching point
MEAsCH Test channel
SwFNCT Switching function
LIMITS
Test channel
Target cleanliness ISO ISO
NAS NAS
Test channel
Target cleanliness ISO ISO
Above limit NAS NAS
Test cycle
60
NAsMAX NAS maximum
NAS NAS
NAS+T NAS + temperature
TEMP Temperature
HDaISO HDA+ISO
HDaSAE HDA+SAE
ISO 4 ISO class 4µm
ISO 6 ISO class 6µm
ISO 14 ISO class 14µm
ISO ISO Code
ISO+T ISO code + Temperature
NAS 2 NAS 2 µm
NAS 5 NAS 5 µm
NAS 15 NAS 15 µm
NAS 25 NAS 25 µm
NAsMAX NAS maximum
NAS NAS class
ISO 4 ISO class 4µm
ISO 6 ISO class 6µm
ISO 14 ISO class 14µm
ISO ISO Code
TEMP Temperature
NAS 2 NAS 2 µm
NAS 5 NAS 5 µm
NAS 15 NAS 15 µm
NAS 25 NAS 25 µm
BEYOND Above limit
BELOW Below limit
WITHIN Within
OUTSDE Outside
OFF off
Limit values
LOWER Below limit
UPPER Above limit
Seite / Page 13 / 16
