Care

Use only warm water with washing up liquid and a soft sponge or cloth.
Warning
Do not use aggressive cleaning agents such as acetone, trichlorethylene or similar;
this could attack the paint and the material.

Technical information

Designation Art.-#
SQlab 8OX 35 mm 2313
SQlab 8OX 5o mm 2063 8 Nm
SQlab 8OX 6o mm 2064 8 Nm
SQlab 8OX 7o mm 2065 8 Nm
SQlab 8OX 8o mm 2066 8 Nm
SQlab 8OX 9o mm 2067 8 Nm
SQlab 8OX 100 mm 2068 8 Nm
SQlab 8OX 110 mm 2069 8 Nm
SQlab 8OX 120 mm 2070 8 Nm
SQlab 8OX ltd. 35 mm 2314
SQlab 8OX ltd. 5o mm 2091 8 Nm
SQlab 8OX ltd. 6o mm 2092 8 Nm
SQlab 8OX ltd. 7o mm 2093 8 Nm
SQlab 8OX ltd. 8o mm 2194
SQlab 8OX ltd. 9o mm 2195
SQlab 8OX
2357
Fabio Wibmer
SQlab 8OX Trial
2355
Fabio Wibmer
Titanium screws kit 2081
max.
length angle weight
torque
8 Nm 35 mm 6° 138 g
50 mm 6° 149 g
60 mm 6° 163 g
70 mm 6° 169 g
80 mm 6° 173 g
90 mm 6° 180 g
100 mm 6° 190 g
110 mm 6° 199 g
120 mm 6° 206 g
8 Nm 35 mm 6° 128 g
50 mm 6° 139 g
60 mm 6° 153 g
70 mm 6° 159 g
8 Nm 80 mm 6° 163 g
8 Nm 90 mm 6° 170 g
8 Nm 35 mm 6° 128 g
6 Nm 90 mm 35° 145 g
Over
lock nut
rise reach
dimen-
sions
3,7 mm 34,8 mm 50 mm
5,2 mm 49,7 mm 50 mm
6,3 mm 59,7 mm 50 mm
7,3 mm 69,6 mm 50 mm
8,4 mm 79,6 mm 50 mm
9,4 mm 89,5 mm 50 mm
10,5 mm 99,5 mm 50 mm
11,5 mm 109,4 mm 50 mm
12,5 mm 119,3 mm 50 mm
3,7 mm 34,8 mm 50 mm
5,2 mm 49,7 mm 50 mm
6,3 mm 59,7 mm 50 mm
7,3 mm 69,6 mm 50 mm
8,4 mm 79,6 mm 50 mm
9,4 mm 89,5 mm 50 mm
3,7 mm 34,8 mm 50 mm
- - 40 mm
Han-
min. head
dlebar
Overlap tube di-
diame-
head tube ameters
ters
32 mm 31,8 mm 28,6 mm
32 mm 31,8 mm 28,6 mm
32 mm 31,8 mm 28,6 mm
32 mm 31,8 mm 28,6 mm
32 mm 31,8 mm 28,6 mm
32 mm 31,8 mm 28,6 mm
32 mm 31,8 mm 28,6 mm
32 mm 31,8 mm 28,6 mm
32 mm 31,8 mm 28,6 mm
32 mm 31,8 mm 28,6 mm
32 mm 31,8 mm 28,6 mm
32 mm 31,8 mm 28,6 mm
32 mm 31,8 mm 28,6 mm
32 mm 31,8 mm 28,6 mm
32 mm 31,8 mm 28,6 mm
32 mm 31,8 mm 28,6 mm
38 mm 31,8 mm 28,6 mm
