RF RC 10 EN868
//
Montage- und Anschlussanleitung / Funkschalter
Mounting and wiring instructions / Wireless switch
Instructions de montage et de câblage / Interrupteur sans fil
Istruzioni di montaggio e collegamento / Interruttore wireless
Instruções de montagem e instalação / Interruptor de rádio frequência
Инструкция по монтажу и подключению / Радио-выключатель
English
Use of the mounting and wiring instructions
Target group: authorised and qualified staff.
All actions described in these instructions may only be performed by
qualified persons who have been trained and authorised by the
operating company.
1. Read and understand these mounting and wiring instructions.
2. Comply with the valid occupational safety and accident prevention
regulations.
3. Install and operate the device.
Selection and installation of devices and their integration in control
systems demand qualified knowledge of all the relevant laws, as well
as the normative requirements of the machine manufacturer.
In case of doubt, the German language version of these instructions
shall prevail.
Scope of delivery
1 device, 1 mounting and wiring instructions, carton.
Intended use
The one-channel wireless switch is used to switch electrical loads via
radio transmission. The receiver must conform to the EnOcean ® proto-
col of the PTM- and STM-modules.
Assignment of the place of use:
Device type Place of use
EN868 EU
Assignment of radio frequency:
Device type Radio frequency
EN868 868.3 MHz
Mounting and wiring
Mount the device on an even surface. Install the device according to
the mounting and wiring instructions of the receiver. The wireless
range depends heavily on the local conditions. Conductive materials
may strongly affect the radio signal. This also includes thin foils, e.g.
aluminium laminations on insulation materials.
Design of wireless range
The radio signal is attenuated on the way from the transmitter to
the receiver. In addition, the radio signal is attenuated/influenced by
obstacles. The degree of attenuation depends on the material of the
obstacle. The following tables serve as a guide.
Penetration of radio signals:
Material
wood, gypsum, glas uncoated
brick stone, press boards
armoured concrete
metal, aluminium lamination, water
Typical wireless ranges:
Place of use
Line of sight in free field
Line of sight in walkways
Line of sight in halls
In individual cases, test the wireless range with the field strength
testing tool:
Transmitter
EN868
N.B.
The transmission of a switching command from the transmitter to the
receiver takes about 80 to 100 ms, based on the EnOcean ® data trans-
mission. The switching signal of a transmitter must not be generated
in a shorter time interval. Otherwise this signal will be suppressed.
according to
Reconstruction and alterations to the device are not allowed. Subject
2014/53/EU (RED)
to technical modifications. steute does not assume any liability for
recommendations made or implied by this description. New claims for
guarantee, warranty or liability cannot be derived from this document
beyond the general terms and conditions of delivery.
Maintenance
With rough conditions, we recommend routine maintenance as follows:
1. Check actuator for easy operation.
2. Removal of all dirt particles.
Cleaning
- In case of damp cleaning: use water or mild, non-scratching,
- Do not use aggressive cleaners or solvents
Clean enclosure on the outside only. Clean enclosure with household
cleaning agents. Do not use any compressed air to clean.
Disposal
- Observe national, local and legal regulations concerning disposal.
- Recycle each material separately.
2 / 12
Device
EPM 300
non-chafing cleaners.
Penetration
90...100 %
65...95 %
10...90 %
0...10 %
Wireless range (approx.)
150 m
15 m
30 m
Material number
1187179
