Scorpius

IDENTIFICATION OF PARTS

Figure 4
10
17
16
No. ITEM
01 Steering
02 Tiller height adjustment
03 Head light
04 Front wheels
05 Footplate cover
06 Seat springs
07 Supporting wheels
08 Rear wheels
09 Charging port (upper)
10 Control panel
11 Throttle
12 Key switch
13 Seat
*Above is only for reference, actual product may vary.
1654767~A_
2
3 5
4
11
13
12
18
No.
14
15
16
17
18
19
20
21
22
23
24
1
6
7
14
19
ITEM
Seat backrest
Seat knob
Battery box
Battery box handle
Charging port (battery box)
Circuit breaker (press when charging scooter for the first
time and when releasing the over-voltage protection)
Tail light / Brake light
Folding/unfolding release lever
N-D lever
Anti-tippers
Rear bumper
Instruction Booklet
