Translation of the Original Operating
Instructions SP/E
Dear customer!
Using these instructions
• makes it easier to get familiar with the device
• prevents malfunctions caused by improper handling, and
• lengthens the service life of your device.
Please keep these instructions readily accessible at all
times.
Use the device only when you have understood it exactly
and always adhere to the instructions.
PROXXON is not liable for the safe functioning of the
device in cases of:
• handling that does not conform to the usual usage,
• purposes of use not designated in the instructions,
• disregard of the safety instructions.
You are not entitled to guarantee claims in cases of:
• operator errors,
• inadequate maintenance.
For your own safety, please follow the safety instructions
exactly.
Use only genuine PROXXON replacement parts.
We reserve the right to make improvements in the sense
of technical progress. We wish you much success with
the device.
Please observe the supplemental safety notes when
working with the SP/E grinding and polishing device.
1. Do not use any damaged or deformed grinding discs.
2. Use only grinding discs recommended by the
manufacturer that are labelled with a rotational speed
equal to or greater than 24 m/s.
Legend
1. Locking button
2. Protection hood
3. Locking screw for protection hood
4. Work piece rest
5. Locking screw for work piece rest
6. Grinding dust drawer
7. On – Off – switch
8. Speed control button
9. Mains supply cable
10. Extraction socket for grinding dust
11. Polishing mandrel

Description of machine

The Proxxon grinding and polishing apparatus SP / E is
the ideal machine for grinding and polishing of various
materials.
The silicium – carbide disc ( grey ) is most suitable for the
grinding of hard materials such as hard metals, grey cast
iron, high speed steels, ceramics and glass as well the
grinding of soft materials such as copper, aluminium and
plastics.
With the special fused alumina disc ( red ) you can grind
tough materials such as non – hardened steel, welding
seams, hardened steel and titanium.
variety of polishing discs are available as accessories.
The required mandrel is included with the machine.
The electronic speed control allows perfect adjustment of
the rotary speed to the polishing job.
The slim housing in the area of the grinding discs also
allows the grinding of longer work pieces.
The strong plastic housing is fitted wit a socket for a
vacuum cleaner.

Technical data

Motor
Voltage
Power
Speed
Machine
Discs
Size
Weight
Grinding speed
Noise leve
Vibration
For use in dry environments only
Protection class II device
Please do not dispose off the machine!
ccessories ( included ):
Polishing mandrel
Operation
Danger !
Safe and accurate work is only possible with the machine
property fastened !
Fasten the machine to a strong table top.
If the machine needs to be portable, it is possible to screw
it onto a strong wooden plate and then to clamp the
wooden plate with C – clamps to the edge of table.
230 V ; 50 Hz
100 W 5/30 min
3000 to 9000 / min
Ø 50 x 13 x 12.7 mm
approx. 250 x 130 x 100 mm
approx. 1200 g
8 to 24 m/s
70 dB ( )
2.5 m/s 2
