WARNING:
Do not attempt to modify this product or create
accessories not recommended for use with this
product. Any such alteration or modification is
misuse and could result in a hazardous condition
leading to possible serious personal injury.
WARNING:
To prevent accidental starting that could cause
serious personal injury, always disconnect the
engine spark plug wire from the spark plug pack
when assembling parts.
INSTALLING THE POWER HEAD SHAFT TO THE
ATTACHMENT
See Figure 2.
WARNING:
Never install, remove, or adjust any attachment
while power head is running. Failure to stop the
engine can cause serious personal injury.
The attachment connects to the power head shaft by
means of a coupler device.
Loosen the knob on the coupler of the power head
Q
shaft and remove the end cap from the attachment.
Push in the button located on the attachment shaft.
Q
Align the button with the guide recess on the power
head coupler and slide the two shafts together.
Rotate the attachment shaft until the button locks into
the positioning hole.
NOTE: If the button does not release completely in the
positioning hole, the shafts are not locked into place.
Slightly rotate from side to side until the button is locked
into place.
Tighten the knob securely.
Q
WARNING:
Be certain the knob is fully tightened before
operating equipment; check it periodically for
tightness during use to avoid serious personal
injury.
REMOVING THE ATTACHMENT FROM THE POWER
HEAD
For removing or changing the attachment:
Loosen the knob.
Q
Push in the button and twist the shafts to remove and
Q
separate ends.
ATTACHING THE HANGER CAP
See Figure 3.
There are two ways to hang your attachment for storage.
To use the hanger cap, push in the button and place
Q
the hanger cap over end of the lower end attachment
IT PT NL SV DA NO FI HU CS RU
English
shaft. Slightly rotate the cap from side to side until the
button locks into place.
The secondary hole in the attachment shaft can be
Q
used for hanging purposes as well.
ATTACHING THE FRONT HANDLE
See Figure 4.
RBC430SES
Install the front handle onto the top side of the drive
Q
shaft boom with the barrier bar on the same side as
the recoil starter (compare to product images in figure
sheet or on giftbox)
Reinstall the clamp, align the screw to the screw hole
Q
on the front handle.
Tighten bolts securely.
Q
RBC430SBS
NOTE: The throttle trigger must be mounted to the
operator's right side.
Remove the clamp (Item 28),
Q
Place the handle in the bracket (Item 30) located on
Q
the shaft housing.
Hold the stamping clamp and align the bolts into the
Q
bracket.
Adjust the handle bar for best operator control in a
Q
comfortable upright position.
Tighten bolts with the stamping wrench to hold the
Q
bike handle securely.
ATTACHING THE GRASS DEFLECTOR
See Figure 5.
Attach the blade guard to the mounting bracket
Q
and align the screw holes on the blade guard to the
screws on the mounting bracket.
Using the combination wrench, tighten all two screws
Q
securely.
NOTE: When using the string head, the grass deflector
must be attached to the blade guard.
Attach the grass deflector to the blade guard and
Q
align the 3 screws on the grass deflector to the screw
holes on the blade guard.
Using the combination wrench supplied, tighten all 3
Q
screws securely.
WARNING
Always stop the engine and remove the spark
plug wire before making any adjustments such
as changing cutting heads; this is to reduce the
risk of serious personal injury.
INSTALLING REEL EASY STRING HEAD
See Figure 6.
Q
Open the Reel easy line trimmer head by depressing the
latches on each side. The contents of the line trimmer head
are spring loaded, so keep your other hand over the line
