Process Display
3

Installation

3.1 Installation
The permitted ambient conditions (see Section 10 "Technical data" in the Operating Instructions)
must be observed when installing and operating. The device must be protected against the
effects of heat.

3.1.1 Dimensions

Please note the installation depth of 150 mm (5.91 inches) for the measuring device plus cable.
Additional dimensions are provided in → Fig. 2 and Section "Technical data" in the Operating
Instructions.
3.1.2 Mounting location
Installation in panel with cutout 92x92 mm (3.62x3.62 inches) (as per ' E N 60529' ) . The
mounting location must be free from vibrations.
3.1.3 Orientation
Horizontal +/- 45° in every direction.
3.2

Installation instructions

The required panel cutout is 92x92 mm (3.62x3.62 inches). Please note the installation depth
of 150 mm (5.91 inches) for the measuring device plus cable.
Installation
25
