GETTING STARTED

Package contents

Components

Wallbox Pulsar Plus
with Charging Cable

Included mounting parts

x2
ø6 x 50mm ø5 x 40mm
Phillips Screws Phillips Screws

Required tools

Small, flat Phillips Screwdriver
Screwdriver
Electric Drill
3/8" (8 mm) bits
Holster
x2
x4
ø8 x 40mm
Wall Anchors
Measuring
or Bit Tape
Stud Spirit Level
Detector
Installation Guide Amperage Reduction
x1
Screw Plug T20 4 x 10mm
(Plug-in Torx Screws
version) (Hardwire version)
T20 Screwdriver
or Bit
Pencil
PULSAR PLUS
Amperage Reduction Label
Wallbox Chargers S.L.
SN: 123456 UID: abcdefgh 08/2020 Made in Spain 20A
PN: PUP1-U-1-5-N-002-A
22ºF to 104ºF (-30ºC to 40ºC)
Enclosure Type 3R
Input/Output:
208/240VAC, 60Hz, 48A
EV Charger
Input/Output: Input/Output: 20A
208/240VAC, 60Hz, 16A 208/240VAC, 60Hz, 16A
EV Charger
Input/Output: Input/Output: 25A
208/240VAC, 60Hz, 20A 208/240VAC, 60Hz, 20A
Input/Output: Input/Output: EV Charger
30A
208/240VAC, 60Hz, 24A 208/240VAC, 60Hz, 24A
EV Charger
Input/Output: Input/Output: 40A
208/240VAC, 60Hz, 32A 208/240VAC, 60Hz, 32A
EV Charger
Input/Output: Input/Output: 50A
208/240VAC, 60Hz,40A 208/240VAC, 60Hz, 40A
Save this label sheet for future use.
Labels
x2 x2
ø3.5 x 9.5mm
Phillips Screws
Torque
Screwdriver
(Hardwired
version)
NEMA 14-50P 240V
outlet
Ground facing down
Or electrical material
to hardwire
