INSTALLATION

Holster

16
Installation height
Outdoor:
18 - 48 " (45 - 120cm)
Indoor:
24 - 4 8" (60 - 120cm)

Installing the holster

The holster is used to store your EV connector
when not in use. You may place the holster
wherever it is most convenient, being sure that
the location does not place any tension on the
charging cable.
1.
For a secure mounting, locate the holster on
a vertical wall stud or similar solid wall. Mark the
two screw holes.
2.
Drill two holes where marked with an
appropriately sized drill bit, align the holster, and
securely fasten the holster with the two provided
screws. Do not over-tighten.
ø5 x 40mm
3.
Drape the charging cable around your
charger and dock your EV connector in the
holster.
• You may drape the charging cable on the
holster, the charger, or both.
Proceed to the instructions for operating
your charger in page 17.
x2
