Getting Started

Thank you for purchasing the Rotel RB-1562 or RB-1572 Stereo Power
Amplifi er. When used in a high-quality music or home theater system,
your Rotel amplifi er will provide years of musical enjoyment.
The RB-1562 and RB-1572 are sophisticated two-channel power
amplifi ers. Their digital amplifi er circuitry, switching power supply,
premium components, and Rotel's Balanced Design ensure superb
sound quality. High current capability allows the RB-1562 and
RB-1572 to drive diffi cult speaker loads with ease.
The RB-1562 and RB-1572 are essentially identical units. They
differ only in power output. In this manual the RB-1562 is most often
depicted, but the RB-1572 operates in the same way.
Operating Features
• Two amplifier channels.
• User selectable power on/off configuration: manual or controlled
by remote 12 volt trigger signal.
• Protection circuitry with front panel indicators.
• Dual binding post speaker outputs.
A Few Precautions
Please read this manual carefully. In addition to installation and
operating instructions, it provides information on various RB-1072
system confi gurations. Please contact your authorized Rotel dealer for
answers to any questions you might have. In addition, all of us at Rotel
welcome your questions and comments.
Save the RB-1072 amplifi er shipping carton and packing material for
future use. Shipping or moving the RB-1072
than the original packing material may result in severe damage to
your amplifi er.
Be sure to keep the original sales receipt. It is your best record of the
date of purchase, which you will need in the event warranty service is
ever required.
Placement
The RB-1072 amplifi er generates heat as part of its normal operation.
The heat sinks and ventilation openings in the amplifi er are designed
to disperse this heat. The ventilation slots in the top cover must be
unobstructed. There should be 10 cm (4 inches) of clearance around
the chassis, and reasonable airfl ow through the installation location, to
prevent the amplifi er from overheating. Likewise, remember the weight
of the amplifi er when you select an installation location. Make sure
that the shelf or cabinet can support its weight.

AC Power and Control

AC Power Input 7
The RB-1072 amplifi er is supplied with the proper AC power cord.
Use only this cord or an exact equivalent. Do not use an extension
cord. A heavy duty multi-tap power outlet strip may be used, but only
if it is rated to handle the current demand of the RB-1072
amplifi er in anything other
amplifi er.
1
Be sure the Power Switch on the front panel of the RB-1072
amplifi er is turned off. Then, plug one end of the cord into the AC
7
power connector on the back panel of the amplifi er. Plug the other
end into an appropriate AC outlet.
Your RB-1072 amplifi er is confi gured at the factory for the proper AC
line voltage in the country where you purchased it (USA: 120 volts/60
Hz, Europe: 230 volts/50 Hz). The AC line confi guration is noted on
a label on the back panel.
NOTE: Should you move your
country, it is possible to configure your amplifier for use on a
different line voltage. Do not attempt to perform this conversion
yourself. Opening the enclosure of the
you to dangerous voltages. Consult a qualified technician or the
Rotel factory service department for information.
If you are going to be away from home for an extended period of
time, it is a sensible precaution to unplug your amplifi er.
1
Power Switch and Indicator
The Power Switch is located on the front panel. To turn the amplifi er
on (or to activate either of the optional automatic power-on modes),
push the switch in. The LED indicator above
light [COLOR?], indicating that the amplifi er is turned on. To turn the
amplifi er off, push the button again and return it to the out position.
Protection Indicator 2
Thermal and protection circuits protect the amplifi er against potential
damage in the event of extreme or faulty operating conditions. Unlike
many designs, the protection circuit of the RB-1562 and RB-1572
is independent of the audio signal and has no impact on sonic
performance. Instead, the protection circuit monitors the temperature
of the output devices and shuts down the amplifi er if safe limits are
exceeded.
In addition, the RB-1510 includes over-current protection which
operates only when load impedances drop too low. This protection
is independent for each channel and is indicated by the front panel
Protection LED.
Should a faulty condition arise, the amplifi er channel at fault will stop
playing and the Protection LED on the front panel will light.
If this happens, turn the amplifi er off, let it cool down for several
minutes, and attempt to identify and correct the problem. When you
turn the amplifi er back on, the protection circuit will automatically reset
and the PROTECTION LED should go out.
In most cases, the protection circuitry activates because of a fault
condition such as shorted speaker wires, or inadequate ventilation
leading to an overheating condition. In very rare cases, highly reactive
or extremely low impedance speaker loads could cause the protection
circuit to engage.
Note: The Protection Mode LED also lights when the 12V Trigger
system is being used and the amplifier is in Standby mode.
to another
RB-1072 amplifi er
exposes
RB-1072 amplifi er
ring around the switch will
7
