MAINTENANCE
GB
POS. DESCRIPTION
52 Gearbox 1700W - Quick
53 Gearbox 2000W - Quick
54 Gearbox 2300/3000W
55 Key 5x5x15
56 Electric motor 1700W 24V
57 Key 6x6x30
58 Electric motor 2000W 24V
59 Electric motor adaptor 2300W
60 Adaptor Key 8x7x35
61 Electric motor 2300W 24V
62 Key 10x8x140
63 Electric motor 3000W 24V
64 Washer 1700W
65 Self-locking nuts 1700W
66 Washer 2000/2300/3000W
67 Screw 2000/2300/3000W
68 O-ring 1700/2000W
MOTORGEARBOX 1700W
85
52
64
65
MOTORGEARBOX 2000W
85
53
MOTORGEARBOX 2300W
54
18
CODE
SLMR17TG7000
SLMR20TG7000
MR3000000000
MBH050515F00
EMF172400000
MBH0606030X0
EMF202400000
MSLADMT23000
MBH0807035X0
EMF232400000
MBH1008140X0
EMF402400000
MBR06X000000
MBD06MXET000
MBR08X000000
MBV0825MXE00
-
56
75
74
55
68
70
71
58
57
68
61
66
67
57
60
59
69
66
67
69 Gasket motorgearbox
2300/3000W
70 Motor casing watertight 1700W
71 Terminal board gasket
72 Terminal board cover
73 Screw
74 Bottom gasket
75 Bottom cover
76 Cable outlets
77 Motor casing watertight 20/2300W
78 Bottom cover O-ring
79 Bottom cover
80 Lower terminal board gasket
81 Upper terminal board gasket
82 Upper terminal board cover
83 Self-tapping screw M3.9x22
84 Self-tapping screw M3.9x32
85 Gearbox flange gasket TG70
MOTORGEARBOX 3000W
54
76
73
72
84
79
78
77
80
RIDER REGAL 1700/2000/2300/3000W - REV004A
PGBMR2000000
PCCCPM100000
PCGPMMR00000
PCCPPMMR0000
MBV02213AXSC
PGGPMFN00000
PCCPPMFN0000
PPM20B000000
PCCCPM200000
PGR035250000
PCCPPMFN2000
PCGPMMR2N000
PCGPMMR2S000
PCCPPMMR2000
MBV03922AXCC
MBV03932AXCC
PGFLRDTG7000
63
62
68
65
66
81
82
84
83
