CONNECTION DIAGRAM

GB
BASIC SYSTEM RIDER-REGAL 1700/2000W
SEE PAGE 44
SHOWING THE MAIN
CONNECTION DIAGRAM
WINDLASS
MOTOR
L4
HYDRAULIC-
MAGNETIC
CIRCUIT
BREAKER
(see table on page 4)
L3
14
MULTI-PURPOSE
WATERTIGHT HAND HELD
REMOTE CONTROL
MOD. HRC 1002
BATTERY
L1
L3
L2
C
FOR WINDLASS OPERATION
WATERTIGHT HAND HELD
CHAIN COUNTER
CHAIN COUNTER
REMOTE RADIO CONTROLS
RECEIVERS
FOOT SWITCHES MOD. 900U AND 900D
BLACK
BROWN
BLUE
FUSE
4A (12V)
2A (24V)
CONTACTOR UNIT
MOD. T6315-24 (24V)
A2
®
QUICK ACCESSORIES
WATERTIGHT
PANEL
TRANSMITTERS
RADIO POCKET - HAND SET
A1
L = L1 + L2 + L3 + L4
RIDER REGAL 1700/2000/2300/3000W - REV004A
WINDLASSES
CONTROL
BOARD
UP
DOWN
