BASIC SYSTEM RIDER-REGAL 2300/3000W
SEE PAGE 45
SHOWING THE MAIN
CONNECTION DIAGRAM
WINDLASS
A
A
S
S
MOTOR
L5
HYDRAULIC-
MAGNETIC
(see table on page 4)
L6
L4
RIDER REGAL 1700/2000/2300/3000W - REV004A
MULTI-PURPOSE
WATERTIGHT HAND HELD
REMOTE CONTROL
MOD. HRC 1002
BATTERY
L1
CIRCUIT
BREAKER
L2
C
CONNECTION DIAGRAM
REMOTE RADIO CONTROLS
RECEIVERS
BLACK
BROWN
BLUE
FUSIBILE
4A (12V)
2A (24V)
L3
REVERSING
CONTACTOR UNIT
MOD. T6415-24 (24V)
A2
®
QUICK ACCESSORIES
FOR WINDLASS OPERATION
WATERTIGHT HAND HELD
CHAIN COUNTER
WATERTIGHT
PANEL
CHAIN COUNTER
RADIO POCKET - HAND SET
FOOT SWITCHES MOD. 900U AND 900D
A1
L = L1 + L2 + L3 + L4 + L5 + L6
GB
WINDLASSES
CONTROL
BOARD
UP
DOWN
TRANSMITTERS
