Tools Required; Scope Of Delivery; Accessories For Rmm Series - Waeco mobitronic RV-RMM-70 Instructions De Montage

The following are required for the installation:
– Scale (ruler) (see B 1)
– prick punch (see B 2)
– hammers (see B 3)
– drill (see B 4)
The following are required for the electrical connection and the check:
– diode test lamp (see B 8)
– or voltmeter (see B 9)
– crimp pliers (see B 10)
– insulating tape (see B 11)
Depending on your individual assembly, you will probably need still more screws, nuts,
washers, metal screws and cable-clips than those contained in the scope of delivery.
No. Quantity Designation
1 1 Monitor (see C)
1.1 1 Monitor
1.2 1 Mounting plate + 4 sheet metal screws 4.2 x 15 mm
1.3 1 Connecting lead of connection box to the monitor, approx. 5 m
1.4 1 Connection box + 4 sheet metal screws 4.2 x 15 mm
1.5 1 Connection cable set, two-core
1.6 1 IR remote control
1.7 1 2 batteries of type AAA
Subject to technical changes!
The following articles are available as supplementation to the RMM series:
Designation
wireless infrared headphone
FM modulator for to feed the audio signal into
the audio system of the vehicle. You will need a Y-RCA cable
Camera RV-24, RV-27 via switch box RV-SWITCH-600
Subject to technical changes and to availability of delivery!

Tools required

– drilling machine
– screwdriver
– screwdriver
– heat shrink hose
– hot-air drier
– hatchet iron
– soldering tin

Scope of delivery

Accessories for RMM series

26
(see B 5)
(see B 6)
(see B 7)
(see B 12)
(see B 13)
(see B 14)
Article No.
HS-10
FM-MOD-10
RV-24/RV-27
RV-SWITCH-600
