Operation of the monitor

The monitor switches on automatically after complete connection with adjacent voltage
supply (POWER DIRECT = ON) or you can switch on the device via
the remote control (key POWER) (see F 1.1).
If a video source is connected and operated, the image appears and the audio signal
is transmitted via the IR-headphone accessory HS-10 (see G 1) or via the car radio
(when using the FM-MOD-10).
Activate the key AV (see F 1.7) when changing the video channel on the remote control.
If you want to modify settings, it can be done via the keys MODE and VOL at the monitor
(see D 1.5/1.6/1.7) or the remote control (see F 1.5/1.4).
The monitor can be turned to both sides and likewise to the rear by approx.15°
(see G 1 and 2).
Use of the headphone HS-10
The monitors RV-RMM-70 and 104 are equipped with an IR-transmitter. It enables the
use of the wireless IR-headphone HS-10 (please refer for more detailed information to the
instructions). When using the monitor, you should stay in the range of approx. 120°
horizontally and 60° vertically in front of it (see G). A trouble-free tone reception can be
ensured then.

Failures

Flickering of the picture
The voltage supply has dropped below 12 V. Charge your vehicle battery. A connecting
lead as short as possible must be provided from the voltage source to the connection
box.
Running of picture
The adjusted video format (COLOR SYSTEM) does not match the video source. Change
the format e.g. from NTSC to PAL.
