Operating elements
Contactor/circuit breaker ambient lightning (see D 1.1)
ambient light (see D 1.2)
push-button to open the monitor (see D 1.3)
infrared-reception window (see D 1.4)
VOL> (see D 1.5)
Button to decrease the volume or function selection/setting in the sub-menu
e.g. brightness, mirror function.
MODE (see D 1.6)
Button to select the function (see also section "Remote control")
VOL< (see D 1.7)
Button to increase the volume or function selection/setting in the sub-menu e.g.
brightness, mirror function.
POWER (see D 1.8)
Contactor/circuit breaker
Terminal block on the upper side of the housing (see D 2)
– CONTROLLER (see D 2.1) Connect the supplied connecting cable from the connection
box to the monitor.
– FM(IR) not allocated (see D 2.2).
– FM(IR) not allocated (see D 2.3).
– Grey terminals (Dome Light) for the integrated ambient light (see D 2.4).
– IR infrared transmitter (headphone) (see D 2.5).
At the front:
– TO MONITOR, plug in the socket of the connecting cable to the monitor (see E 1).
Plug in the socket until it audibly engages.
– INPUT VIDEO 1 and 2, 2 sockets (RCA) video input 1 and 2 (see E 2).
– Socket supply line, 2-pole socket (see E 3).
The supply line consists of 2 branch lines:
red = 12 V – max. 15 V
black = earth
At the rear:
– INPUT AUDIO 1 and 2, 4 sockets (RCA) audio input 1 and 2, stereo (see E 4).

Monitor

Connection box
