Carry out a function test before the assembly.
If an interior light should be installed in the vehicle at a suitable place e.g. between
driver- and front seat passenger, the ceiling monitor can be installed at this place. Check
that connecting cable has sufficient length from the place of assembly to the
connectionbox.
Caution! Make sure that the monitor can be fastened
sufficiently at the assembly place (see H 1.4). Is the roof lining stable enough?
Is it possible to achieve sufficient firmness with screws (see H 1.5)?
Test whether the monitor can be opened (see H 1.5).
Caution! The ambient light must be without power in order to avoid
short-circuits of the monitor during the installation. Remove the ambient light
(see H 1.1). Install the mounting plate (see H 1.2). Lay the connecting cable from
the monitor to the intended installation place of the connection box. Connect the
service line of the original ambient light to the connections of the monitor (there is
no need to take into account a polarity) (see H 1.3). Plug the connecting cable into
the socket (see H 1.6).
The safety regulations must be absolutely observed.

Installation of the connection box

The assembly place must be protected against humidity. An assembly under the
dashboard is recommendable due to the compact design.
The box can be fastened with the supplied sheet-metal screws or self-adhesive Velcro
tape (not included in the scope of delivery).
Observe the safety- and installation instructions!
The voltage supply should be provided via a switched voltage source e.g. group 15.
The system has also a certain power consumption when it is switched off
(IRreception active), which can discharge the vehicle battery over a longer period of time.
The connection box provides inputs for 2 video sources (see I 2). This can be a
DVD player (WAECO Art.-No. DVD-PL-10), a camera etc. Plug the RCA cable of the video
sources into the sockets VIDEO/AUDIO (see I 2). A mono-audio signal is produced when
using only one audio input.
Installation of the monitor
