Cleaning The Lawn Mower; Cleaning The Battery; Maintenance; Removing And Attaching The Blade - Stihl RMA 2 RV Notice D'emploi

English
► Hold the lawn mower at transport handle (1) and upend.

16.2 Cleaning the Lawn Mower

► Switch the lawn mower off, pull out the activation key and
remove the battery.
► Clean the lawn mower with a damp cloth.
► Remove any foreign bodies from the battery compartment
and clean the battery compartment with a damp cloth.
► Clean the electric contacts in the battery compartment
with a paintbrush or a soft brush.
► Clean the ventilation slots with a paintbrush.
► Upend the lawn mower.
► Clean the area around the blade and the blade with a
stick, a soft brush or a damp cloth.

16.3 Cleaning the Battery

► Clean the battery with a damp cloth.

17 Maintenance

17.1 Removing and Attaching the Blade

17.1.1 Removing the Blade
► Switch the lawn mower off, pull out the activation key and
remove the battery.
► Upend the lawn mower.
54
► Block blade (1) using a piece of wood (2).
► Unscrew screw (3) in the direction of the arrow and
remove together with washer (4).
► Remove blade (1).
► Discard screw (3) and washer (4).
Use a new screw and washer to attach blade (1).
17.1.2 Attaching the Blade
► Switch the lawn mower off, pull out the activation key and
remove the battery.
► Upend the lawn mower.
► Lay new washer (1) on new screw (2) with the convex side
facing outwards.
► Apply Loctite 243 thread locker to the thread of screw (2).
17 Maintenance
0478-131-9950-A
