GB
F D E
SERVICE
Servicing requires extreme care and knowledge and
should be performed only by a qualified service technician.
For service we suggest you return the product to your
nearest AUTHORISED SERVICE CENTRE for repair.
When servicing, use only identical replacement parts.
WARNING
Observe all normal safety precautions related to
avoiding electrical shock.
WARNING
To avoid serious personal injury, do not attempt
to use this product until you read thoroughly and
understand completely the operator's manual.
Save this operator's manual and review
frequently for continuing safe operation and
instructing others who may use this product.
WARNING
The operation of any power tool can result in
foreign objects being thrown into your eyes,
which can result in severe eye damage.
Before beginning power tool operation, always
wear safety goggles or safety glasses with side
shields and a full face shield when needed.
We recommend Wide Vision Safety Mask for use
over eyeglasses or standard safety glasses with
side shields. Always use eye protection.
SAVE THESE INSTRUCTIONS.
SPECIFICATIONS
Voltage
Power
Air velocity
Air volume
Mulching ratio
Dust bag capacity
Measured sound power level
Guaranteed sound power level
Vibration level
Voltage
Power
Air velocity
Air volume
Mulching ratio
Dust bag capacity
Measured sound power level
I P NL S DK
RBV-2200
220-240V~ 50 Hz
2,200 W
237 Km/h
16 cbm/min
10:1
45 L
101 dB (A)
107 dB (A)
< 25 m/s
RBV-2400VP
220-240V~ 50 Hz
2,400 W
185~237 Km/h
10~16 cbm/min
10:1
45 L
97 dB (A)
N FIN GR HU CZ RU
English
Guaranteed sound power level
Vibration level
DESCRIPTION
1. Shoulder Strap
2. Rear Handle
3. On/Off Switch
4. Speed Control Dial (Model RBV-2400VP only)
5. Front Handle
6. Motor Housing
7. Nozzle
8. Guide Wheels
9. Patio Head (Model RBV-2400VP only)
10. Dust Bag
11. Blower / Vac Mode Selection Lever
12. Power Cable & Plug
13. Live Tool Indicator
14. Dust Bag Holder
ASSEMBLY
ATTACHING THE NOZZLE (Fig.2)
The nozzle (7) comes in two sections. Assemble the
■
sections by slotting them together as shown in Fig. 2.
Ensure the sections have clicked into place and are
aligned properly. Fasten the sections together at the
top and at the bottom, with screws provided.
Slide the assembled nozzle into the motor housing
■
(6). With the latches at the top and at the bottom,
lock the nozzle in place.
ATTACHING AND REMOVING THE DUST BAG
(10) (Fig.3 & 4)
Latch the front of the dust bag holder (14) to the front
■
of the dust exhaust and then lift the dust bag handle
side until the dust bag holder secures to the housing.
See Fig. 3.
Hang the strap at the front of the dust bag to the
■
2
bottom of the nozzle. See Fig. 4.
When removing the dust bag, detach the strap from
■
nozzle first, then press the release on the dust bag
holder and gently dislodge the dust bag off the motor
housing.
SHOULDER STRAP (1) (Fig.3)
Attach the metal fixture of the shoulder strap to the
■
hole just in front of the ON/OFF switch.
10
RO PL SLO HR TR EST LT
CAUTION
Do not use the Blower/Vac in the vacuum mode
without the dust bag (10) in place.
LV SK BG
107 dB (A)
< 25 m/s 2
