FAR RAC 2200 Traduction Des Instructions Originales page 32

Tab. 1/2
No. CODE Q.ty
01A 711973 1 Seeger ring AV 16
02A 710845 1 Stop ring
03 710901 1 Gasket B-102070
04A 710821 1 Anti-extrusion ring
05 712281 1 Piston
06 711119 1 Spring
07 711120 1 Spring
08 710850 1 Spring guide plug
09 710818 1 Container connector
10 710838 1 Out put connector
11B 710819 1 Nails container
12 717004 1 Nozzle for rivet ø 4,8 Cu / Steel
13 710843 1 Sleeve carrying nozzle
14 710300 1 Gasket OR 020
15 710859 1 Clamps holding cone
16 71345507 3 High-performance clamps
17 710849 1 Clamps opener
18 710853 1 Spring
19H 710834 1 Suction sleeve
20 710102 1 Gasket OR 113
21H 710858 1 Cone holder
22H 710832 1 Expeller extension
23 710854 1 Balancer hook
24 710916 1 Gasket OR 2-015
25 710917 1 Gasket OR 2-118
26 710855 1 Sleeving gasket
27 710577 1 Gasket B-086055
28 710908 1 Washer
29 711974 1 Seeger ring JV 22
30 710824 1 Push button
31 710919 1 Gasket OR 2-004
32 710847 1 Valve body
33 710528 1 Gasket OR 008
34 710848 1 Valve piston
35 710918 1 Gasket OR 2-005
36 710842 1 Suction regulation knob
37 710385 4 Gasket OR 2-006
38 720812 1 Handgrip
39 711060 1 Oil-dynamic cylinder
42 710906 1 Washer 400-020-4490
43 710839 1 Oil tank plug
44 711035 1 Washer
45 710931 1 Gasket OR 614
46 711037 1 Connector
47 711039 1 Rotating connector
48 711061 3 Gasket OR 5-614
49 711038 1 Fixed connector
50 710921 1 Gasket OR 2-115
51 711036 1 Reduction
52 711073 1 High pressure tube mt 1,8
54 711084 2 Connector 6700 - ø 5
55 711059 2 Rilsan tube ø 5 x 3,5 x 2600
56 711031 1 Ending handgrip connector
57 717006 1 Nozzle for rivet ø 2,4
58 717001 1 Nozzle for rivet ø 2,5 ÷ 3,4
59 717002 1 Nozzle for rivet ø 4
60 717003 1 Nozzle for rivet ø 4,8 All.
61 717005 1 Nozzle for rivet ø 6 / 6,4
62 711092 1 Wrench 5 mm
63 710969 1 Oil container
64B 711136 1 Air conveyor
65C 710186 1 Gasket OR 010
66C 711401 1 End bush
32
SPARE PARTS
DESCRIPTION KIT
A
A
A
B
H
H
H
B
C
C
750306 - RAC 2200 – rev 12 - ( 01 - 2022 )
GB
No. CODE Q.ty
KITA 740821 Anti-extrusion ring kit
01A 711973 1 Seeger ring AV 16
02A 710845 1 Stop ring
04A 710821 1 Anti-extrusion ring
KITB 740819 Nail tank kit
11B 710819 1 Nails container
64B 711136 1 Air conveyor
KITC 741401 End bush kit
65C 710186 2 Gasket OR 010
66C 711401 2 End bush
KITH 740858 Cone holder kit
19H 710834 1 Suction sleeve
21H 710858 1 Cone holder
22H 710832 1 Expeller extension
It indicates that the part is sold in kits consisting
KIT
of different parts in different quantities.
RAC 2200
KIT
DESCRIPTION
