3.1. GERÄTEBESCHREIBUNG
1
4
3
1.
Curlpult
2.
Stangenhalter
3.
Basiselement
4.
Sitz
3.2. VORBEREITUNG FÜR DIE NUTZUNG
Verzeichnis des Bestandteile:
Nr. Teil
Beschreibung
Anzahl/
Stck.
1.
Schraube M8 x 20
4
2.
Unterlage M8
4
3.
Steckverbinder
3
4.
Höhenverriegelung
3
5.
Schraube M10 x 70
4
6.
Unterlage M10
8
7.
Mutter M10
4
8.
Blende
4
9.
Sitzkissen
1
10.
Sattelstütze
1
11.
Curlpult
1
12.
Stütze des Curlpults
1
13.
Stangenhalter
1
14.
Basisteil des Handgriffs
1
für die Stange
15.
Basiselement
1
16.
Querelement der Basis
1
Zusammensetzen des Geräts:
11
2
1
2
12
9
3
3
2
10
1
4
4
3
4
7 6
15
6
7
5 6
16
8
1.
Die Basis (15), das Querelement der Basis (16) und
die Auflage des Curlpults (14) zusammenschrauben.
Die Blenden (8) an den Enden der Basiselemente
anbringen.
2.
Die Steckverbinder (3) an den in der Abbildung
dargestellten Stellen anbringen.
3.
Befestigen Sie den Sitzbügel (10), das Curlpult (12)
und den Stangenhalter (13), indem Sie ihn durch
Einschrauben des Schlosses (4) in der gewünschten
Höhe arretieren.
4.
Befestigen Sie das Sitzkissen (9) und das Curlpult
(11).
3.3. REINIGUNG UND WARTUNG
•
Reinigen Sie das Gerät nach jedem Gebrauch.
Schweißspuren mit einer Säurereaktion verursachen
Schäden an der Polsterung.
•
Verwenden Sie zum Reinigen der Oberfläche
ausschließlich Mittel ohne ätzende Inhaltsstoffe.
•
Zum Reinigen nutzen Sie bitte einen weichen Lappen.
•
Bewahren Sie das Gerät an einem trockenen, kühlen,
vor Feuchtigkeit und direkter Sonneneinstrahlung
geschütztem Ort auf.
4
5
EN USER MANUAL
TECHNICAL DATA
Parameter description
Product name
Model
13
Maximum user weight
[kg]
Maximum load on the
barbell holder [kg]
Height adjustment
range for the barbell
holder [mm]
14
Dimensions of the arm
curl [mm]
Height adjustment
6
5
range of the arm curl
[mm]
8
Dimensions of the
seating [mm]
Adjustment range of the
seating [mm]
Dimensions [mm]
Weight [kg]
1. GENERAL DESCRIPTION
The user manual is designed to assist in the safe and
trouble-free use of the device. The product is designed
and manufactured in accordance with strict technical
guidelines,
using
components. Additionally, it is produced in compliance
with the most stringent quality standards.
DO NOT USE THE DEVICE UNLESS YOU
HAVE THOROUGHLY READ AND
UNDERSTOOD THIS USER MANUAL.
To increase the product life of the device and to ensure
a trouble-free operation, use it in accordance with this user
manual and regularly perform the maintenance tasks. The
technical data and specifications in this user manual are
up to date. The manufacturer reserves the right to make
changes associated with quality improvement.
LEGEND
Read the instructions before use.
PLEASE NOTE! Drawings in this manual are for
illustration purposes only and in some details may
differ from the actual machine.
The original operation manual is in German. Other language
versions are translations from German.
2. USAGE SAFETY
ATTENTION! Read all safety warnings and all
instructions. Failure to follow the warnings and
instructions may result in serious injury or even
Parameter value
death.
Whenever „device" or „product" are used in the warnings
Preacher Curl Bench
and instructions, it shall mean <Preacher Curl Bench.
GR-RC50
1.
In case of doubt whether the product operates
120
correctly, or in case damage is discovered, please
contact the service centre of the manufacturer.
2.
Only the service centre of the manufacturer can
100
make product repairs. Do not attempt to make any
repairs yourself!
510÷720
3.
Do not overload the device. Exceeding the maximum
permissible user weight can damage the product.
4.
Maintain the device in a good technical state. Before
each use check for general damage and especially
600x300
check for cracked parts or elements and for any other
conditions which may impact the safe operation of
the device. If damage is discovered, hand over the
810÷960
device for repair before use.
5.
Keep the device away from children and animals.
6.
Before you start training, consult a doctor in
order to discover whether there are any health
240x370
counterindications.
7.
Always do a warm up before you start using the
450÷550
device.
8.
In case you feel distressing symptoms such as chest
pain, dizziness, short breath, etc. during training, you
910x565x(810÷960)
should immediately stop the training and consult
the doctor.
12,4
9.
Put the device on a stable, dry and flat surface,
taking care to keep the minimum space 0,5 m of free
space around.
3. USE GUIDELINES
The Preacher Curl Bench is a device designed to perform
state-of-the-art
technologies
and
shoulder muscle training by applying the appropriate
exercises.The product is intended for home use only!
The user is liable for any damage resulting from non-
intended use of the device.
3.1. DEVICE DESCRIPTION
4
1
2
3
