Programming The Clearray - Jacuzzi J-LXL Manuel D'installation Et Utilisation Et Entretien

I
Selecting the Circulation Pump Filtration Cycle
Press and hold the Jets pump 1 (
same time for 3 seconds to access the circulation pump pro-
gramming.
Once you have entered the circulation pump filtration cycle, con-
tinually press the Warmer (
up through the cycles below.
Then select a cycle and press the Jets pump 1 (
tivate that cycle. Upon pressing the jets pump 1 button the sys-
tem will save your selection, exit the program menu and return
to the main menu.
Note: After 10 seconds the programming screen will revert back to
the temperature if no buttons are pressed. You cannot have more
than one circulation pump cycle activated at a time.
0 hours of circulation per day
4 hours of circulation per day
8 hours of circulation per day (recommended
factory default setting)
12 hours of circulation per day
16 hours of circulation per day
20 hours of circulation per day
24 hours of circulation per day
Note: The recommended factory default setting for the JLX Col-
lection is 8 hours. This setting should not be altered. Running
the circulation pump less than the factory recommended time
might result in issues with water quality maintenance.
Programming the Clearray (Ultraviolet)
Programming the CLEARRAY System (U) or Corona Discharge
Ozone (O3) (where included)
Press and hold the Jets pump 1 (
at the same time for 3 seconds. Scroll pass the circulation pump
programming menus by pressing the Warmer button.
Press Press
Press Press
Will select "03"
Will select
"O3" option
option and exit
and exit menu
menu
Press Press
Press
Press
Will take you Will take
back to "C0"
you back to
"C0"
1
) and ( ) button at the
) or Cooler ( ) button to scroll
1
) button to ac-
1
) and Cooler (
Press Press
Press Press
Press Press
Press Press
1
After the last cycle, "C6", the LED screen will display "U" or "O3". If
the LED screen is displaying "U" then pressing the Jets pump 1 will
change the sanitizing system from "U" to "O3" and exit the pro-
gramming menu. If the LED screen is displaying "O3" then press-
ing the Jets pump 1 will change the sanitizing system from "O3"
to "U" and exit the programming menu. You will see one of the t-
wo configurations below:
A. C0, C1, C2, C3, C4, C5, C6, U, 365 (duration countdown timer)
B. C0, C1, C2, C3, C4, C5, C6, O3, =
Note: For the O3 option the "=" disables the duration countdown
timer. If you do not wish to change the option do not press any but-
tons and after 10 seconds the display will return to the main menu.
If the CLEARRAY System has been selected, when the time allotted
has expired (365 days) the display screen will flash between the wa-
ter temperature and "blb". At this time the UV lamp bulb must be re-
placed, the quartz tube must be cleaned and the duration count-
down timer needs to be reset.
I
Resetting the duration countdown timer (CLEARRAY System
only)
Once the duration countdown timer for the CLEARRAY System
has reached zero, you will need to reset it, replace the UV lamp
bulb and clean the quartz tube.
To reset the duration countdown timer:
Press
Press
Press
Press
1
Will reset the timer to Will reset the timer
to 365 days and exit
365 days and exit the
the menu
menu
Press and hold the Jets pump 1 (
at the same time for 3 seconds.
Press the Warmer (
If the timer has reached "0", pressing the Jets pump 1 (
ton will reset the counter. If the timer is not at "0" pressing the Jets
pump 1 button will not reset it.
Note: If the spa power is interrupted, the duration countdown
timer is not affected. The number of days remaining is stored in
) button the memory and will continue to countdown once power is re-
gained.
If the duration countdown timer is not at "0" and you need to reset it:
A. Press and hold the Jets pump 1 and Cooler buttons at the
Press
Press
same time for 3 seconds.
B. Press the Warmer button to scroll to "U".
C. Press the Jets pump 1 button to switch from "U" to "O3".
C. Press and hold the Jets pump 1 and Cooler buttons at the
same time for 3 seconds.
E. Press the Warmer button to scroll to "O3".
D. Press the Jets pump 1 button to switch from "O3" to "U". The
timer has been reset to 365 days.
30
Press Press Press
Press Press
Press
Press Press Press
Press Press Press
1
) and Cooler (
) button until the display shows "0".
Press
Press
) button
1
) but-
