Description of the machine

Machine Parts and Labels

Figure 1
1.
Identification plate:
code, serial number, EC marking, year of manufacture,
weight (kg)
2. Dust container
3. Closing band lever
4.
Main switch
5. Dust container release lever
6. Inlet
7. Plug for closing the side container
8.
Air outlet
9. Attention plate
the operator's attention to the fact that the filter must be
shaken only when the machine is off (see par. "Shaking
the primary filter" as well).
10. Panel power plate
the panel is powered by the voltage indicated on the data
plate
11. Attention plate (tension)
The access to the panel is allowed to specialized personnel
only who, before touching the electrical equipment, must
disconnect the machine from its power source by turning the
main switch (4) to 0- (off) and by removing the plug from the
electrical socket.
This machine creates a strong air flow which is drawn in through
the inlet (6) and blows out through the outlet (8).
Before turning on the machine, fit the vacuum hose into the
inlet and then fit the required tool on to the end part (refer to the
manufacturer's accessory catalogue or Service Centre).
The diameters of the authorized hoses are indicated in the
Technical data table.
The machine is equipped with a main filter which enables it to
be used for the majority of applications.
In addition to the primary filter that retains the most common
dust, a secondary filter (absolute filter) can be installed.
This machine is equipped with an internal baffle plate which
subjects the vacuumed substances to a circular centrifugal
movement that makes them drop into the container.
Figure 2
Vacuum cleaners for dust harmful to health are classified
according to different dust classification, in compliance with
standard EN 60335-2-69 – Annexe AA:
1. Class L label
2. Class M label
3. Class H label
The class H label reads the following.
Model
and service the machine, including removing the
means used to vacuum the dust. Do not use without
the complete filter system in place.

Optional kits

Draws
Various optional kits are available for converting the machine:
■ Level gauge for liquid vacuuming;
Indicates that
■ Removable separator;
■ Clamp and bracket;
■ Machine lifting systems;
■ Upstream absolute filter;
■ Downstream absolute filter;
■ Cartridge filter;
■ Activated carbon filter;
■ Grill and depressor;
■ Grille and valve;
■ Electric filter shaker;
■ Diffuser;
■ Vacuum arm;
■ Limiting valve.
On request, the machine can be supplied with optional kits
already installed. However, they can also be installed at a later
date.
Please contact the sales network for further details.
Instructions describing how to fit the optional kits and the
relative operation and maintenance manuals are supplied
together with the optional kits.
Use only supplied and authorised genuine spare parts.

Accessories

Various accessories are available; refer to the manufacturer's
accessory catalogue.
Use only genuine accessories supplied and authorised
by the manufacturer.
5
3707 - 3707/10 - 3907 - 3907W - 3907/18
CAUTION!
This vacuum cleaner
hazardous for the health.
Only authorised personnel wearing suitable
personal protective equipment should empty
CAUTION!
CAUTION!
contains dust
