Operating Manual WindControl

Connection Plan and Terminal Configuration

Plug-in location
for radio receiver
control LED
24V
1 2 3 4 5 6 7
AN2 wind
transmitter
LS10
light sensor
Power supply
Outputs
Trip capacity
Running time
Connection options
Dimensions
Protection type
Wind sensitivity
potentiometer
Red
10
5 15
0 20
m/s
8 9 10
External
(key)
switch

Technical Data

230V, +10%/-15%; 50-60Hz
2 closers (UP/DOWN potential-free)
4A
3 min.
External key for UP/DOWN
LS10 light sensor
AN2 wind transmitter
138 x 119 x 48 mm (W x H x D)
IP54
WindControl
24V 230V
F1 A/T
11 12 13 14 15 16
C L N L
Mains 230V/50Hz
~ M
Drive 230V/50Hz
Terminal configuration:
1
AN2 wind transmitter
2
3
LS10 light sensor
4
5 External key switch supply
6 UPWARDS position
7 DOWNWARDS position
8 PE
9 PE
10 PE
11 Motor
12 Motor
13
C L jumper
14
15 Mains N
16 Mains L
L1
N
PE
E
N
G
L
I
S
H
23
